ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
Specifications
Brand Name :
TRT
Model Number :
ST/PC MM DX 3.0mm
Certification :
ISO, CE
Place of Origin :
Guangdong, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T,
Supply Ability :
8000pcs/day
Delivery Time :
3-5 working days
Packaging Details :
PP bag then in carton
Material :
LSZH
Fiber :
MM 50/125
color :
Orange
Insertion Loss :
< 0.2dB
Polished :
PC
Length :
1M,3M, 5M or custom
Description

ST/PC-ST/PC Multinode 50/125 fiber patch cable LSZH orange Jacket

Description:

  1. Type: ST/UPC-ST/UPC-MM-DX-3.0mm-3M
  2. Mode: Multimode
  3. Ferrule End-face: PC, UPC
  4. Cable core: Duplex
  5. Cable diameter: 2.0mm, 3.0mm
  6. Cable length: 1m, 2m, 3m….customized

Application:


Telecommunication
CATV, FTTH, LAN
Fiber oiptic sensors
Optical transmission system
Test equipment

Features:

Screw-thread coupling mechanism
Ceramic ferrules connectors
Low insertion loss, high return loss
Excellent mechanical endurance
High credibility and stability
Good in repeatability and exchangeability
100% Insertion, Return Loss, End Face and Interference inspection


Technical Data


Parameter
Unit
FC, SC, LC
ST, MU
MTRJ, MPO

SM
MM
SM
MM
SM
MM
SM

PC
UPC
APC
PC
PC
UPC
PC
PC
UPC
PC
PC
APC

Insertion Loss
dB
≤0.3
≤0.2
≤0.3
≤0.2
≤0.3
≤0.2
≤0.2
≤0.3
≤0.2
≤0.2
≤0.3
≤0.3

Return Loss
dB
≥45
≥50
≥60
≥30
≥45
≥50
≥30
≥45
≥50
≥35
≥55
≥75

Repeatability
dB
≤0.1

Durability
dB
≤0.2dB typical change, 1000 matings

Operating temperature
ºC
-20 ~ +75

Storage temperature
ºC
-40 ~ +85


Ordering Information


Connector
Fiber Core
Cable Diameter
Fiber Type
Polishing
Cable Jacket
Cable Color
Fiber Length

LC
SC
FC
ST
D4
MU
DIN
SMA
MPO
MTRJ
Simplex
Duplex
0.9mm
2.0mm
3.0mm
SM:9/125um
MM:50/125um MM:62.5/125um
OM3
PC
UPC
APC
PVC
LSZH
Yellow
Orange
Aqua
others
1M
2M
3M
10M
20M
30M

ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket

ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
