SC UPC OM3 50/125 Fiber Optic Pigtail Aqua Fiber Optical Patch Pigtail For Network
SC UPC OM3 50/125 Fiber Optic Pigtail Aqua Fiber Optical Patch Pigtail For Network
SC UPC OM3 50/125 Fiber Optic Pigtail Aqua Fiber Optical Patch Pigtail For Network
SC UPC OM3 50/125 Fiber Optic Pigtail Aqua Fiber Optical Patch Pigtail For Network
Specifications
Brand Name :
TTI
Model Number :
SC(OM3)
Certification :
CE / ROHS
Place of Origin :
Shenzhen,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, , ,Paypal
Supply Ability :
5000 Pieces / Day
Delivery Time :
2-3 Days
Packaging Details :
Boxes
Name :
Optical fiber pigtail
Type :
SC UPC OM3
Color :
Aqua
Material :
ABS
Application :
FTTH FTTB FTTX Network
Fiber Length :
50-62.5 um
Connector :
UPC
Certication :
CE / ROHS
Min Quantity :
100 Pieces
Insert loss :
Low
Description

SC UPC OM3 50/125 aqua fiber optical patch pigtail for network

Features:

100% test before shipment

Low insertion loss and high return loss

Serialized & Individual Test Records

Meets ROHS and Bell core GR 326-core standards

Custom Configurations Available at No Extra Charge

Available in fiber bunch, ribbon fan-out, pigtail available

Applications:

Optical access network

Data processing networks

Premise installations

Telecommunication networks

Fiber optic communication networks

CATV, LAN, WAN, Test &Measurement

Specification:

Parameter Single Mode Multi Mode
Basic Fiber connector FC, SC, LC, ST, MU, MTRJ, MPO
Ferrule End-face PC UPC APC UPC
Insertion Loss ≤0.2dB ≤0.2dB ≤0.3dB ≤0.3bB
Return Loss ≥50dB ≥55dB ≥60dB ≥35dB
Ceramic Ferrule Specification 125.5um concentricity deviations:<=1um 127um concentricity deviations:<=3um
Suitable Fiber 9/125um 50/125um,62.5/125um
End-face Geometry Radius of Curvature 7~25mm 5~12mm N/A
Fiber Protrusion ≤50nm ≤100nm N/A
Fiber Under Cut ≤100nm ≤100nm N/A
Apex offset ≤50um
Mechanical Exchangeability ≤0.2dB
Salt Spray ≤0.1dB
Drop ≤0.2dB(1.5M, 5 drops)
Vibration IL ≤0.2dB(550Hz, 1.5mm)
Repeatability ≤ 0.1dB(1000 times)
Durability > 1000 times
Operating Temperature -40°C ~ +85°C

SC UPC OM3 50/125 Fiber Optic Pigtail Aqua Fiber Optical Patch Pigtail For Network
