Specifications
Brand Name :
TTI
Model Number :
MPO Fiber Patch Cord
Certification :
ISO RoHS CE UL
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
, paypal , T/T, L/C
Supply Ability :
10000 pieces perday
Delivery Time :
2-5days
Packaging Details :
pe bag in carton
Brand type :
OEM
Length :
Customized
Mode :
SM/MM
Polish :
UPC,APC,PC
Description

High quality MPO fiber optic patch cord/cable/jumper

1,Product Description

MPO optical fiber patch cord, Precise connector, Customized length,

Excellent mechanical capability, insertion loss<0.2dB, Good durability and exchangeability,

Compliant with Telcordia GR-326-CORE, TIA/EIA and IEC standard

2,Application

CATV

Active dvice termination

Telecommunication networks

Metro

Local Area Networks(LANs)

Data Processing networks

Test Equipment

Premise installations.

Wide Area Networks(WANs)

3,Feature

Low insertion loss and back reflection loss

Good echangeabilityGood Durability

High temperature stability

Standard: Telcordia GR-326-CORE

4,Specification

Mode SM MM
Polish UPC/APC PC
Insertion Loss

Typical ≤0.2dB

Maximum ≤0.3dB

 ≤0.25dB
Return Loss

≥50DB(PC)

≥60DB(APC)

 ≥30dB
Interchangeability ≤0.2dB
Repeatability ≤0.1dB
Durability ≤0.2dB typical change, 1000 matings
Tensile Strength > 10kg
Temperature ≤0.2dB (-40+85 sustain 100 hours)
Humidity ≤0.2dB (+25+65 93 R.H.100 hours)

5,Ordering options

Boot (cable size) Boot Color Fiber Type Cable number Ferrule Length

0.9mm

2.0mm

3.0mm

Black

Biege

Blue

Gray

White

Yellow

9/125um SM

50/125um MM

62.5/125um MM

OM3

OM4

Simplex

Duplex

Multi-fiber

PC

APC

Customized

MPO LC / SC / FC / ST Fiber Optic Patch Cord MPO LC / SC / FC / ST fiber jumperMPO LC / SC / FC / ST Fiber Optic Patch Cord MPO LC / SC / FC / ST fiber jumper

MPO LC / SC / FC / ST Fiber Optic Patch Cord MPO LC / SC / FC / ST fiber jumper MPO LC / SC / FC / ST Fiber Optic Patch Cord MPO LC / SC / FC / ST fiber jumper MPO LC / SC / FC / ST Fiber Optic Patch Cord MPO LC / SC / FC / ST fiber jumper
