FA-TCX10L23-20, 10 Gigabit Small Form Factor Pluggable XFP Fiber Transceiver Single Fiber 1270/1330nm SM 20KM

Ethernet is the most widely used technology in the high performance LAN environment. Like Gigabit Ethernet, 10G Ethernet also supports single mode or multimode fiber. The use of 10G Ethernet enables network operators to choose the location of the data center more freely and can support multiple Park networks within 80 km at the same time. In the data center, the lower cost multimode fiber can be used as the backbone of the 10G network between switches and switches, or switches and servers. When the 10G backbone is built, the operators can provide high bandwidth services such as video streaming, medical images, and so on.

Ethernet is with advantages like low cost, wide application and backward direction. In Metro Ethernet, data packets from the server can be output from Ethernet port , go to copper through the transmission network, finally arrive at the user terminal, without any disassembly or protocol conversion of the data frame, all the metropolitan area is Ethernet. 10G Ethernet can guarantee this seamless connection functionally. In the 10G Metro Ethernet, the network nodes between the server side and the end stations can all use the 10G Ethernet switching device, or the DWDM technology transmission device can support the intermediate data transmission.

10G Ethernet can connect the Internet and the general network through the SONET/SDH network. Because 10G Ethernet has WAN network port, the connection is very convenient and the cost is very low. It is important to note that when 10G Ethernet is connected to the Internet through the SONET/SDH network, it also needs to consider the security and management of network access.

10G Ethernet not only has high transmission speed, but also greatly improves its transmission distance. It can support both single mode fiber connection and multi-mode optical fiber connection. The transmission distance of 10G Ethernet connected by single-mode optical fiber can reach 80 km. Generally speaking, 10G Ethernet technology basically inherits Ethernet, fast Ethernet and Gigabit Ethernet technology, so it has great advantages in user popularity, ease of use, network interoperability and simplicity.

Fiberall provides a full range of 10G fiber optic transceivers including XFP, SFP+ and so on. Please contact us if you need help on these optical transceivers.

Main Features

With single +3.3V/+5V power supply;

With LVPECL/PECL data interface;

Meets the requirement of GR-468-CORE;

Conforms to Laser Class 1, meets the requirement of IEC60825-1;

Fiberall supply the XFP transceiver conforms to the requirements of RoHS;

Single fiber bidirectional optical module (BIDI).

Electrical Characteristics

(Ambient Operating Temperature -5°C to +70°C, Vcc =3.3 V)
