Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber
Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber
Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber
Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber
Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber
Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber
Specifications
Brand Name :
Fiberall
Model Number :
FA-AD-SA1SP-P
Certification :
RoHS
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union, MoneyGram,PayPal
Delivery Time :
3-5 days
Packaging Details :
Plastic Bag or Blister Box/Carton
Product Name :
SC Optical Adapter
Suitable end face :
APC
Fiber capacity :
Duplex
Screw hole :
Two holes
Main Material :
Plastic
Housing Color :
Green
Description

FA-AD-SA1SP-P,Green SC APC Optical Adapter With Mounting Hole For Duplex Single Mode Fiber

Standard single-mode fiber is a single-mode fiber with zero dispersion wavelength in the 1.3um (1310nm) window, and the International Telecommunication Union (ITU-T) defines the fiber as G652 fiber. Its characteristic is that when the working wavelength is 1.3um (1310nm), the dispersion of the fiber is very small, and the transmission distance of the system is limited by the attenuation of the optical fiber. However, the loss of this fiber in the 1.3um (1310nm) band is about 0.3dB/km~0.4dB/km, and the loss in the 1.55um band is about 0.2dB/km~0.25dB/km. The dispersion in the 1.3um (1310nm) band is 3.5ps/nm. Km, larger in the 1.5um band and about 20ps/nm km. This fiber can be used to support the trunk system in the 1.55um band of 2.5Gb/s, but because of the larger in the dispersion band, if 10Gb/s signal transmission, the transmission distance of more than 50 km, requires the use of a dispersion compensation module is expensive.

Our single mode fiber optic adapter is universal and compatible with all standard single mode G652, G655 and G657 fibers. There is no compatibility problem during use, please feel free to use.

Specification Of SC/APC Fiber Optic Adapter

Item Parameter
Fiber Type Single mode
Adapter Specification Fiber Adapter SC/APC SM DX Green
Housing Appearance Green
Fiber Channel Duplex
Main Material Plastic
Sleeve Material Ceramic(ZrO2) or customized
Test wavelength 1310nm or 1550nm
Insertion Loss (IL) standard value <0.3dB
Repeatability ≤0.10dB
Interchangeability ≤0.20dB
Operating Temperature -20ºC ~ +70ºC
Storage Temperature -40ºC ~ +85ºC

Main Characteristics

1.Low insertion loss and high return loss;
2.Universial type with excellent compatibility;
3. Precision alignment and high reliability;
4.Good environment and temperature stability;
5.With flange and screw mounting hole, easy for installation;
6.Ceramic or brass sleeve are available for options;
7. ROHS Compliant.
