24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
24 Core Mountable SC ST FC LC Optical Network Terminal Box
Specifications
Brand Name :
CY COM
Model Number :
FDB-0208A
Certification :
ISO9001:2015, SGS,ROSH
Place of Origin :
Shenzhen,China
MOQ :
20Pcs
Payment Terms :
T/T, Western Union
Supply Ability :
10K/Month
Delivery Time :
3-8 days
Packaging Details :
Plastic foam and Cartons
Size :
200*215*54mm
Material :
ABS
Applied adaptor :
SC ST FC LC
Port :
4 / 8
Max capacity :
8 cores
Color :
White /Black
Cable ports :
2 whaterproof round ports,8 ports cable out
Application :
Wall mount, pole mount or Aerial-hanging
Description

24 Core Mountable SC ST FC LC Optical Network Terminal Box

8 12 16 24 core FTTH BOX Terminal Optical fiber cable distribution box Wall an pole mountable

Description

FTTH terminal box are used in the end termination of residential buildings and villas, to fix and splice with pigtails. Can be installed on the wall. May adapt variety of optical connection styles. Optical fiber can be managed effectively. Fixed and splied with pigtails.It can be istalled on the wall.Can adapt variety of optical connection syles.

Features

  • PLC splitter is compatible with 3 wavelength (1310/1490/1550)
  • Low insertion loss and high directivity, high quality, reliability, and performance
  • Available for : 1x8, 2x8
  • FTTH network and CATV system application
  • Suitable for SC Duplex 4 ports. Or Quad LC adapters
  • Design to protect splitter
  • Bracket preparation that can be fixed when installing it on wall
  • Application for outdoor, IP65 grade

Application:

l Wall-mounted Installation

l Pole-mounted Installation

l Aerial-hanging Installation

l Suitable for Huawei pre-connectorized drop cable with reinforced connector

Specification:

ITEM FDB0208A
Dimensions 205*215*55mm
Max Capacity 8 core
Weight 0.25kg
Cable input port 1 round
Cable output capacity 2 round cable in ,8 round cable out
Protection Level IP-55
Atmospheric pressure 70KPa~106 KPa
Operation Temperature -40 ~ +85°C

Main Technical

 Insertion loss: ≤0.2dB
UPC return loss ≥60 dB
APC return loss >1000 times

24 Core Mountable SC ST FC LC Optical Network Terminal Box24 Core Mountable SC ST FC LC Optical Network Terminal Box

24 Core Mountable SC ST FC LC Optical Network Terminal Box
