Specifications
Brand Name :
CY COM
Model Number :
SC Female to male
Certification :
ISO9001:2015,ISO14001:2015,ROSH
Place of Origin :
Shenzhen China
MOQ :
10pcs
Payment Terms :
T/T, Western Union
Supply Ability :
50K / Month
Delivery Time :
5-8days
Packaging Details :
PE bag
Material :
Zinc Alloy
Attenuator value :
1-30dB customized
Cap color :
White/Green/Black
Type :
Female to Male
Return Loss :
PC:≥50 UPC: ≥55 APC: ≥60
Storage Temperature :
-40℃~+ 85℃
Description

SC APC Female To Male Zinc Alloy Optical Variable Attenuator

Introduction:

Fiber Optic Attenuator is a component installed in a fiber optic transmission system that reduces the power in the optical signal.
It is often used to limit the optical power received by the photo detector to within the limits of the optical receiver.

Features:

Low back reflection and Low PDL

High precision attenuation value

Precision control of attenuation range

Wide attenuation range

Precision ceramic ferrule

Metal housing material

Application:

Fiber optical telecommunication system
Fiber optical CATV
Fiber optical sensor
Testing equipment

Specification:

Item Unit Parameter
Operating Wavelength nm SM:1310/1550nm MM: 850 /1300nm
Attenuation Range dB 1-10dB(1dB step), 15, 20, 25, 30dB
Return Loss dB PC:≥50 UPC: ≥55 APC: ≥60
Attenuation Tolerance dB ≤+/-0.5(1-10dB) or ≤+/-1.0(11-30dB)
Working Temperature ℃ -25℃~+75℃
Storage Temperature ℃ -40℃~+ 85℃

4. Ordering information:

  • Attenuation type: female & male, fixed, in-line, variable
  • Connector type: FC, SC, LC, ST
  • Ferrule end-face: PC, UPC, APC
  • Core type: single mode (SM:9/125μm), multi mode (MM: 50/125μm or 62.5/125μm)
  • Attenuation value: 1dB, 3dB, 5dB, 10dB, 15dB, 20dB, 30dB(1-30dB)

SC APC Female To Male Zinc Alloy Optical Variable Attenuator

SC APC Female To Male Zinc Alloy Optical Variable Attenuator
