SC Square Type and Round Type Bare Fiber Adapter for Fiber Temporary Connections
SC Square Type and Round Type Bare Fiber Adapter for Fiber Temporary Connections
SC Square Type and Round Type Bare Fiber Adapter for Fiber Temporary Connections
SC Square Type and Round Type Bare Fiber Adapter for Fiber Temporary Connections
Specifications
Brand Name :
FURONG
Model Number :
BARESCSQ
Certification :
ROHS, ISO
Place of Origin :
GUANGDONG
MOQ :
1
Price :
Negotiable
Packaging Details :
Plastic Tray
Shape :
SQUARE AND ROUND
Connector Type :
SC
Construction :
Metal
RoHS Compliant :
YES
Connector Color :
Blue
Reusable :
YES
Description

Description:

The Bare Fiber Adaptor enables quick and easy temporary connections of singlemode fibers. This adaptor is very useful for connecting fibers to power meters. Optical timedomain reflectometers (OTDRs) and a variety of other instruments, enabling insitute functional testing without having to attach a permanent connector. The bare fiber is secured in place with a special precision cut foam pad to ensure kink and diffusion free operation, and repeatable measurements. Fibers with buffer sizes of up to 900 µm can be accommodated. Piano wires for cleaning blocked ferrules are included with all adapters.

We supply SC bare fiber adaptor with stable qualities that use high quality Ceramic Ferrules and precise Fiber connector housing parts in round shape and square type.

Features:

--Low insertion loss

--Good repeatability

--Easy to use

--Length: 40MM, Diameter: 13MM

--Temperature cycle test:-40-+80 °C

--Interchangeability < 0.2dB

--Convenient operation, can be observed by the naked eye

--Reusable, single mode / multi-mode fiber can be used

--Low insertion loss, good reflecting inhibition

Application:

--Bare fiber connector device production

--Visible fault location

--Testing fiber on the reel

--Optical fiber through connection test

--Two-way communication during optical-fiber cable installation and maintenance

--First-aid repair,temporary connection and testing on optical fiber project

Specification:

Shape Square / Round
Connector SC/PC
Applicable fiber SM & MM
Ferrule diameter 123-127 um
Ferrule outder diameter 2.499mm 1.249mm
Cable diameter 250um & 900um
Insertion Loss ≤0.20dB
Repeat ability ＜0.2dB
Tensile strength 100g
Plug time >1000 times
Operating Temperature -40 ~+85℃
Size Length:40mm, diameter:30mm

SC Square Type and Round Type Bare Fiber Adapter for Fiber Temporary ConnectionsSC Square Type and Round Type Bare Fiber Adapter for Fiber Temporary Connections
