Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket
Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket
Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket
Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket
Specifications
Brand Name :
FURONG
Model Number :
FTTH Self Support Bow-type
Certification :
ROHS
Place of Origin :
Guangdong, China (Mainland)
MOQ :
100KM
Price :
negotiation
Payment Terms :
T/T or western Union, D/P
Supply Ability :
10,000km per month
Delivery Time :
7 working days after received your payment
Packaging Details :
Wooden drum，paper case
Jacke :
PVC or LSZH
Steel :
0.45mm
core :
2
Fiber :
G652D, G657A
Shape or structure :
can be produced as per buyer's request
OEM :
acceptable
Description

Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket

Special Curved Optical Fiber, Providing Greater Bandwidth And Enhanced Network Transmission Characteristics;
* Two Parallel Fiber Optic Cable, FRP Has A Good Compression Performance, Can Protect The Fiber;
* Cable Structure Is Simple, Light Weight, Strong Practical;
* Unique Groove Design, Easy Peeling, Convenience For Connect, And Simplify Installation And Maintenance;
* LSZH Fire-Retardant Jackets, Environmental Protection And Safety.

Descriptions:

The Struture Of Indoor Optical Ftth Cable: In The Centre Is The Optical Communication Unit, With The Parallel Non-Metical Enhanced FRP Of The Two Side. The Sheath Materiar Is Lszh Or PVC.
*The Cable Model Specifications, Size And Strength Can Made The Suitalbe Adjust According To The Customer's Requirements.

Instructions:
1. "Xn" Means The Table That Fiber Models. Can Use G. 652, G. 657, G. 655 Single-Mode Optical Fiber Or A1a, A1b Multimode Fiber;
2. Delivery Length: 1 Km, 2km Or Other User-Specified Length;
3. According To The Yd/T1258.5-2005 Jacket Color, Or It Can Also Be A User Of Other Colors As Customers Requriements;
4. Jacket Materials Can Also Be Use Other Materials As Requriements;

Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant JacketMini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket
Our advantage
1. Professional cable manufacturer. Low Price High Quality!
2. We provide good quality FTTH cable with manufacture competitive price
3. Best delivery time
4. OEM service provide,Your own logo and own design are welcomed.
5. Long distance factory review by video talk
6. Can be customized production of fiber optic cable
7. 30 years cable service life , even 60 years cable service life.

Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket
Mini Self-Supporting FTTH Fiber Optic Cable Bow Type , LSZH Fire-Retardant Jacket

Technical parameters:

Items

unit

Details

Fiber counts

--

1-4

Optical fiber

Type

--

G.657

Two parallel Steel wire strength member

--

0.45mm FRP

LSZH sheath

--

YES

Cable diameter

mm(±0.1)

(2.0±0.2)*(3.0±0.2)

Cable weight

(Kg/Km)

10.5+

Tension (Long/Short Term)

N

100/200

Crush (Long/Short Term)

N/100mm

1000/2200

Min. Bending radius

Short term

20times cable diameter

Long term

10times cable diameter

Temperature range

Storage

-20°C to 70°C

Operation

-20°C to 70°C

Application

indoor
