Specifications
Brand Name :
OPTFOCUS
Model Number :
OFS-DSS-20
Place of Origin :
Shenzhen China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
5000 pieces per one week
Delivery Time :
5-7 working days
Packaging Details :
107mm x 82mm x 77mm
Product Model :
OFS-DSS-20
Forwarding Mode :
Store-and-Forward
Forwarding Rate :
148800pps/port
Power consumption :
2.5W
Working temperature :
-10～55℃
Storage temperature :
-20～75℃
Product Weight :
0.5 KG
Product size (L×W×H) :
69*50*24mm
Description

100 Mbps mini Fiber to ethernet media converter with dual fiber single mode SC 20km

Product Description

Technical Specifications

Technical items Description
Product Name 10/100M Media Converter
Product Model OFS-DSS-20
Connector Dual Fiber: 1* 100Mbps,SC/ST/FC Optional
RJ45: 1*10/100Mbps,Auto MDI/MDI-X
Network Media 10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter)
Fiber Media Fiber ( Multimode): 50/125, 62.5/125μm(the max distance up to 2km or 5km)
Fiber( Singlemode): 8.3/125, 8.7/125, 9/125, 10/125μm(the max distance up to 100km)
Forwarding Mode Store-and-Forward
Forwarding Rate: 148800pps/port
Operating standard EEE802.3, IEEE802.3u ,IEEE802.3z,IEEE802.3ab,IEEE802.3x
Power (external) Input:AC 100~250VOutput:DC 5V 1A ,(default).
or Input:DC:-36V~-72V；Output:DC 5V 1A .(Optional)
Power consumption 2.5W
LED Power, FX 100,Link/Act, TX 100,FDX, Link/Act.
Working Environment Working temperature: -10～55℃ ;
Storage temperature: -20～75℃
Relative Humidity: 5%~95 %( no condensation)
Packing List 1× Media Converter
1×User Manual/Certificate of quality/Warranty card
1×power adapter
MTBF 100,000 hours
Weight & Size Product Weight: 0.5 KG
Packing weight: 1.1 KG
Product size (L×W×H): 69*50*24mm
Packing size(L×W×H):107cm× 82 cm×77 cm
Warranty 1-years

Feature:

  • 1 Port 10/100Mbps with Auto Uplink™ , 1 port 100Mbps fiber

  • Comply with IEEE 802.3, IEEE 802.3u 10/100Base-TX, 100Base-FX Standard

  • Auto negotiation function allows UTP port to auto select 10M or 100M and Full Duplex or Half Duplex

  • UTP port supports MDI / MDI-X auto crossover.

  • Supporting 1552 bytes packet

  • Extend fiber distance up to 2km for multi-mode fiber and 20-120km for single-mode fiber

  • Data Transfer Rate:
    　- TP: 10/100Mbps - FX: 100Mbps

  • Duplex mode support:
    - Full or half-duplex mode by Auto-Negotiation (TP)

  • LED indicators: Power, FX 100, FX Link/Act, TX 100, TX FDX, TX Link/Act

  • Design of external power supply for selection by end-users

Product Exhibition

OEM&ODM Support 10/100M Ethernet Fiber Media Converter

Single Mode Gigabit Media Converter 2.5W Power Consumption With 1 Years Warranty

Single Mode Gigabit Media Converter 2.5W Power Consumption With 1 Years Warranty

Single Mode Gigabit Media Converter 2.5W Power Consumption With 1 Years Warranty

Single Mode Gigabit Media Converter 2.5W Power Consumption With 1 Years Warranty

Application

Single Mode Gigabit Media Converter 2.5W Power Consumption With 1 Years Warranty
