1*1000M UTP SC 20km Fiber Media Converter Rx1550nm
1*1000M UTP SC 20km Fiber Media Converter Rx1550nm
1*1000M UTP SC 20km Fiber Media Converter Rx1550nm
1*1000M UTP SC 20km Fiber Media Converter Rx1550nm
Specifications
Brand Name :
OPTFOCUS
Model Number :
OFS-GS-20
Place of Origin :
China
MOQ :
300 pcs
Price :
10 usd per unit
Payment Terms :
T/T, Western Union
Supply Ability :
5000 pcs per month
Delivery Time :
7 days after deposited
Packaging Details :
Box/Carton
Certification :
CE ISO
Keyword :
Media converter
Data Rate :
1000M
Fiber port :
1*1000M SC
Distance :
20/40/60/80/120km optional
Wavelength :
Tx1310nm Rx1550nm
Working Temp :
0-55 deg
Storage Temp :
-22 - 75 deg
Warranty :
1 year
Description

media converter price mini media converter sc media converter 20km

Description

OFS-GS-20 Series Fiber Media Converter is the conversion equipment of Ethernet optical-electronic signals between 10/100/1000M UTP interface (TX) and 1000M Fiber interface (FX). The traditional 10/100/1000M Fast Ethernet can be extended to the distance of 120km through optical fiber link. The performance and quality of the products are excellent because of adopting latest IC. 6 Group LED indicated lights could fully monitor the working conditions of Converters. It is easy for users to observe the network operations. The Series products with reasonable price are especially designed for network users.OPTFOCUS Series Converters could be used alone;

The converters can be used as a stand-alone unit or as a slide-in module to the OPTFODUS Media Converter Chassis, OFS-RACK-14. As the other OPTOFUS OFS-Series media converters, they're hot swappable in MC-Chassis.

Technical Specifications

Product Name 10/100/1000M Media Converter
Product Model OFS-GS-20
Connector Dual Fiber: 1* 1000Mbps,SC/ST/FC Optional
RJ45: 1*10/100/1000Mbps,Auto MDI/MDI-X
Network Media

10BASE-T: Cat3,4,5 UTP(≤100 meter)

100BASE-TX: Cat5 or later UTP(≤100 meter)

1000BASE-TX: Cat6 or later UTP(≤100 meter)
Fiber Media

Fiber ( Multimode): 50/125, 62.5/125μm(the max distance up to 2km or 5km)

Fiber( Singlemode): 8.3/125, 8.7/125, 9/125, 10/125μm(the max distance up to 100km)
Forwarding Mode Store-and-Forward
Forwarding Rate: 1488000pps/port
Operating standard EEE802.3, IEEE802.3u ,IEEE802.3z,IEEE802.3ab,IEEE802.3x
Power external

Input:AC 100~250VOutput:DC 5V 1A ,(default).

or Input:DC:-36V~-72V；Output:DC 5V 1A .(Optional)
USB power supply(Optional).
Power consumption 2.5W
LED Power, Link/Act, TX 1000,TX 100,FDX, Link/Act.
Working Environment

Working temperature: -10～55℃ ;

Storage temperature: -20～75℃

Relative Humidity: 5%~95 %( no condensation)

Other Specification

Installation DIN-Rail or Wall mounts,Optional,Default device is not
Packing List

1× Media Converter

1×User Manual/Certificate of quality/Warranty card

1×power adapter
MTBF 100,000 hours
Weight & Size

Product Weight: 0.5 KG

Packing weight: 1.1 KG

Product size (L×W×H): 94.5*70*26mm

Packing size(L×W×H):215*138*56mm
Warranty 1-years

DIP Switch:

SW1 ON Enable LFP
OFF Disable LFP
SW2 ON Cut-through
OFF Store-and-Forward
SW3 OFF No function
SW4 OFF No function
