Product Model | 8+8 |
Basic Featrue | |
Fixed Port | 8 10G SFP+ optical ports,8 10/100/1000M RJ45 adaptive electrical ports |
Console Port | 1 |
Backplane Capacity | 178Gbps |
Packet Forwarding Rate | 132.43Mpps |
Jumbo Frames | 12k bytes |
Transfer Mode | Support store-forward mode and cut-through mode |
CPU | 600 MHz ARM Cortex-A9 single-core processor |
MAC Address Table | 16K |
Packet Buffer | 2MB |
VLAN ID | 4K |
Flash Memory Capacity | 8MB |
Memory Capacity | 512MB DDR3 SDRAM |
Soft Specification | |
Security Feature | IP+MAC+PORT+VLAN binding ARP inspection DOS prevention Port protection IP source port protection |
VLAN | Port based VLAN 802.1Q VLAN IP based VLAN MAC based VLAN |
MAC Address Table | Static MAC address table Dynamic MAC address table |
Storm Control | Broadcast suppression Multicast suppression DLF suppression Limiting rate |
Flow Control | Half-duplex control based on the back pressure type Full-duplex control based on the PAUSE frame |
Port Mirroring | Support port mirroring |
Port Management | General setting Port counting Configuring port Port trunking Port-isolation |
QoS | IEEE 802.1Qau Congestion mechanism Each port has 8 transmitting queues mapping 802.1p 8 priority |
IP Services | Ping detection DHCP Snooping |
Spanning Tree | MSTP(802.1s),STP,RSTP |
Multicast Management | IGMP Snooping multicasting packets detection |
System Management | Support SNMP v1/v2 Support Console Support TELNET Support WEB interface |
Remote Upgrading | Support version upgrading via web Support version upgrading via local |
Physical Characteristics | |
Dimension | 440mm × 285mm × 44mm |
Characteristic of Power | AC: 110V~260V |
Power | ≤100W |
Indicator | Power indicator, system indicator, connecting / transceiver indicator |
Environment Temperature /Humidity | operating temperature: 0°C~50°C (0m~1800m) storage temperature: -40°C~+70°C, relative humidity: 5%RH~95%RH, Non-condensing |
Shenzhen OPTFOCUS Technology Co., Ltd was established in 2009, which is a High -tech manufacturer enterprise with 10 years' experience in global sales and services. Our company focus on professional R & D, production and sales of XPON access equipments, FTTH/FTTx solution and passive cabling system products. We also committed to provide Customized OEM & ODM services to Global communication distributors, Telecom Operators and System Integrator. OPTFOCUS manufacturing center covering area around 2,500 Square meter, and owning three production workshops, 9 production lines.
Advantage of our company :
1 National High-tech enterprise certification;
2 Fiber Optical Innovative &production team Over 10 years;
3 Fiber optical active and passive components production Workshop;
4 Strict quality management system;
5 Professional One stop supply & service;
6 OEM&ODM available;
7 Reliable and Timely customer services;
FAQ:
1. who are we?
We are a 12 years manufacturer specialize in fiber optic communication equipment
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Switch,GPON ONU,EPON ONU
4. How many days can shipment after ordered?
