Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler
Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler
Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler
Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler
Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler
Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler
Specifications
Brand Name :
Geehe Comm
Model Number :
GH-OS-WDM-06
Certification :
ISO9001:2015, ISO:14001,GR-1221-Core
Place of Origin :
China Mainland
MOQ :
180 pcs
Price :
Negotiation
Payment Terms :
T/T, MoneyGram, Western Union, L/C, D/A
Supply Ability :
600 pcs/ day
Delivery Time :
With 7-9 days after confirmed the order
Packaging Details :
Plastic box per pc with Pressure defense sponge, outer carton
Module Name :
Fiber Optic WDM Coupler
Port Type :
1 x 2 (1 x N, Optional)
Fiber Type :
PM Panda fiber
Jacket :
250um or 900nm or others
Connector :
With connector or without connector optional
Pigtail Length :
1M or customized
Common Pass port :
PM980 or PM1550
Option Channel :
4, 8 , 16, 18 channels
Operating Wavelength :
980~1550 nm
Description


High-Reliability Mini Type 0.9mm 1x N Fiber Optic WDM Coupler


Product Information:

WDM is an abbreviation for Wavelength-Division Multiplexing and is now one of the most widely used technology for high-capacity optical communication systems.

The WDM Module is expanding the bandwidth of Metro/Access Networks. The 4-channel and 8-channel CWDM modules are based on Wavelength Division Multiplexer devices. T

WDM is widely used for Long-haul telecommunication, Access/PON distributions, CATV networks.


WDM Benefit&Features:

  • High uniformity and reliability
  • High wavelength repeatability
  • Low insertion and return loss
  • Low polarization dependent loss
  • Built with Corning G657A
  • Wide Wavelength Range
  • Excellent Channel Isolation
  • Connectors can be chosen


WDM Applications:

  • Optical power monitoring for flex grid networks
  • OSA module for test and measurement equipment
  • Feedback control signal for power balancing at DWDM
  • Monitoring power for gain equalization
  • Monitoring ROADM networks
  • Datacenter

Mini Type 0.9mm 1x2 1x4 1x N Fiber Optic WDM Coupler



Specifications& Technology Parameters:

Fiber Type(dB) Corning HI1060flex or OFS BF05635-02 SMF-28e
Operating Wavelength(nm) 980 & 1550 1060 & 1550 1310 & 1550 1480 & 1550
Operating Bandwidth(nm) ±10/20 ±15 ±15
Grade P A P A P A P A
Insertion Loss(dB) ≤0.15 ≤0.25 ≤0.30 ≤0.40 ≤0.2 ≤0.3 ≤0.3 ≤0.35
Isolation(dB) ≥20 ≥18 ≥20 ≥18 ≥25 ≥18 ≥25 ≥18
PDL(dB) ≤0.05 ≤0.1 ≤0.05 ≤0.1 ≤0.05 ≤0.1 ≤0.1 ≤0.1
Directivity(dB) ≥55
Operating Temperature(℃) -40 ~ +85


* The above specification is excluding the connector
* Other specification can be made on customer requires

Ordering Information:

WDM- N- XX- XX- X- XX- XX- X
95:980&1550nm 135:1310&1550nm 65:1060&1550nm 45:1480&1550nm 01: :SMF-28e
02: HI1060flex,
03: OFS BF05635-02		 1:1m
X:customization		 25:250μM Fiber
09:900μM loose Fiber 20: 2mm cable
30: 3mm cable		 SC:SC/UPC
SA:SC/APC
......
00:No connector		 A: A
B: B
C:C
Grade Operation Wavelength Fiber Type Fiber Length Pigtail Type Connect Type Dimension
