FBT Steel Tube 3×5 20/80 Fiber Optic Cable Coupler for FTTX PON
FBT Steel Tube 3×5 20/80 Fiber Optic Cable Coupler for FTTX PON
FBT Steel Tube 3×5 20/80 Fiber Optic Cable Coupler for FTTX PON
FBT Steel Tube 3×5 20/80 Fiber Optic Cable Coupler for FTTX PON
Specifications
Brand Name :
Geehe Comm
Model Number :
GH-FO-3×5
Certification :
CE,ISO9001:2015,ISO14001,RoHS
Place of Origin :
Wuhan China
MOQ :
100 pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T,Ali Pay,, Western Union
Supply Ability :
2,800 Pcs Per Day
Delivery Time :
Within 7-9 working days after confirm the order
Packaging Details :
Plastic box per pc with pressure defense sponge, outer carton
Model Name :
Fiber optic couplers and splitters
Optical Coupler Configuration Type: 1x2 Operating Wavelength :
1310nm,1490nm,1550 nm
Split ratio :
50/50,40/60,30/70,20/80,10/90,5/95 etc
Other Types :
Singlewindow, Dualwindow,Triplewindow
Function :
Fiber distribution
Available pre-terminated :
LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC, and ST/UPC
Polarization Alignment :
Slow Axis or Fast Axis
Fiber Type :
PM Fiber Cable
Package Type :
Steel Tube
Configuration Type :
3×5 bare fiber no connectors
Description

FBT Steel Tube Fiber Optic Cable Coupler No Connectors for FTTX PON

Optic Coupler Brief Introduces:

FBT splitter utilizes precision technology to combine or distribute light from single/multiple inputs to single/multiple outputs bi-directionally. They are designed for power splitting and tapping in telecommunication equipment, CATV networks, and test equipment.

Geehe's optic couplers can do:1×2,2×2,1×3,2×3,1×4,2×4,3×5,3×8 etc.

Fiber Optic Coupler Features& Benefits:

  1. Steel tube-compact size
  2. Wide Operating Temperature and Wavelength
  3. Excellent Environmental & Mechanical Stability
  4. Low insertion loss and polarization-dependent loss
  5. High optical return loss
  6. Better uniformity

FBT Steel Tube 3×5 20/80 Fiber Optic Cable Coupler for FTTX PON

Wide Brand Coupler Specification and parameter:

Parameter P A
Operating Wavelength(nm) 1310&1550
Operating Bandwidth(nm) 1310 ± 40nm,1550 ± 40nm
Fiber Type(dB) Corning G652D OR Corning G657 A1
Insertion Loss
(dB)		 50/50 ≤3.3 ≤3.5
40/60 3.70~4.40≤2.5 3.50~4.60/≤2.8
30/70 5.00~5.60/≤1.8 4.90~6.10/≤2.1
20/80 6.80~7.40/≤1.2 6.50~7.70/≤1.2
10/90 9.60~10.50/≤0.6 8.80~11.40/≤0.8
5/95 12.70~13.50 /≤0.4 12.05~14.05/≤0.5
3/97 14.60~15.50/≤0.3 13.60~16.05/≤0.4
2/98 16.60~17.90/≤0.25 15.60~18.20/≤0.3
1/99 19.20~20.80/≤0.2 18.80~21.40/≤0.25
PDL(dB) ≤0.1 ≤0.15
Return Loss(dB) ≥55 ≥45
Directivity(dB) ≥55
Operating Temperature(℃) -40 ~ +85

* The above specification is without connector

* Other specifications can be made on customer request

Ordering Information:

WBC- X- X2- 35- XX- X- XX- XX- X
P: Premium
A: Grade A
X: Customization		 12:1x2
22:2x2		 35:1310/1550nm 01: 01:99
02: 02:98
……
50: 50:50		 1:1 m
x: Customization		 25:250μM Fiber 09:900μM loose fiber SC: SC/UPC SA: SC/APC
00: no connector		 A: A
B: B
C:C
Grade Port number Operating wavelength Coupling ratio Fiber length Fiber type Connect type Dimension

EX:WBC-P-12-35-50-1-09-0-B

Fiber Optic Coupler Application:

  • FTTx Systems
  • LAN, WAN and Metro Networks
  • Analog/Digital Passive Optical Networks
  • Long-haul telecommunication
  • Mini sizes transmitter/receiver module
  • Optical communication system

Wuhan Geehe Service:

1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity


2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space


3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards

4) Factory Audit

We cooperate with famous brands and Japanese customers, with 15 years of factory inspection experience and be familiar with the whole inspect process by SGS
