Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
Specifications
Brand Name :
Geehe OEM
Model Number :
GH-FO-2×2
Certification :
CE,ISO9001:2015,ISO14001,CE
Place of Origin :
Wuhan China
MOQ :
500 pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T,Ali Pay,, Western Union
Supply Ability :
2.800 Pcs Per Day
Delivery Time :
Within 7-9 working days after
Packaging Details :
Plastic box per pc with pressure defense sponge, outer carton
Model Name :
Multi-Mode 2x2 Optical Coupler
Optical Coupler Configuration Type: 1x2 Operating Wavelength :
1310nm,1490nm,1550 nm
Split ratio :
50:50,30:70,10:90,5:95,1:99
Other Types :
Singlewindow, Dualwindow,Triplewindow
Device Type :
Fused Coupler
Available pre-terminated :
LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC, and ST/UPC
Fiber Length :
1m,3m,5m or OEM
Fiber Type :
PM Fiber Cable
Package Dimension :
Ø4x 40;Ø4x 54;98x16x9 mm
No. Of Fibers :
1 Fiber Inoput,2 Fiber output
Description

OM4 Fiber 1x3 Single Window 900μm Fiber Optic Coupler Insertion Loss

Fiber Optic Coupler Brief Introduces:

Geehe Comm as the No.2 Fiber Optic Coupler manufacturer in the Asian-Pacific district has the most advanced technology for FBT Couplers, not only based on our most advanced machines but also be dependent on our skilled workers.

FBT couplers are designed for power splitting and tapping in telecommunication equipment, CATV networks, and test equipment.

The more Split ratio is available:50:50,30:70,10:90,5:95,1:99 etc

1× 2,2×2 FIber Optic Coupler Features& Benefits:

1) Low insertion loss and excess loss

2) Low polarization dependence

3) High optical return loss

4) Environmental Stability and Reliability

5) Small package size

6) Qualified Under Telcordia GR-1221 and GR-1209

Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler

Three Window Wide Brand Coupler Specification and parameter:

Parameter P A
Operating Wavelength(nm) 1310&1490&1550
Operating bandwidth(nm) 1310 ± 40nm,1490± 40nm,1550 ± 40nm
Fiber Type(dB) Corning G652D OR Corning G657 A1
Insertion Loss
(dB)		 50:50 ≤3.4 ≤3.6
30:70 5.00~5.60/≤1.8 4.90~6.10/≤2.1
10:90 9.60~10.50/≤0.6 8.80~11.40/≤0.8
5:95 12.70~13.50 /≤0.4 12.05~14.05/≤0.5
1:99 19.20~20.80/≤0.2 18.80~21.40/≤0.25
PDL(dB) ≤0.1 ≤0.1
Return Loss(dB) ≥50 ≥45
Directivity(dB) ≥55
Operating Temperature(℃) -40 ~ +85

* The above specification is without connector

* Other specifications can be made on customer request

Ordering Information:

WBC- X- X2- 345- XX- X- XX- XX- X
P: Premium
A: Grade A
X: on request		 12:1x2
22:2x2		 1310&1490&1550nm 01: 01:99
05: 05:95
……
50: 50:50		 1:1 m
x: on request		 25:250μM Fiber 09:900μM Loose Fiber SC: SC/UPC SA: SC/APC
00:no connect		 A: A
B: B
C:C
Grade Port Number Operation Wavelength Coupling Ratio Fiber Length Fiber Type Connector Type Dimension


EX:WBC-P-12-345-50-1-25-00-A

FBT Coupler Compare With PLC Splitter:

Parameters FBT Splitter PLC Splitter
Fabrication Method Two or more pieces of optical fibers are bound together and put on a fused-taper fiber device. The fibers are then drawn out according to the output branch and ratio with one fiber being singled out as the input. Consists of one optical chip and several optical arrays depending on the output ratio. The optical arrays are coupled on both ends of the chip.
Operating Wavelength 1310nm and 1550nm (standard); 850nm (custom) 1260nm -1650nm (full wavelength)
Application HFC (network of fiber and coaxial cable for CATV); All FTIH applications. Same
Performance Up to 1:20– reliable. For larger splits, reliability can become an issue. Good for all splits. High level of reliability and stability.
Input/Output One or two inputs with an output maximum of 32 fibers. One or two inputs with an output maximum of 64 fibers.
Package Steel Tube (used mainly in equipment); ABS Black Module (Conventional) Same
Input/Output Cable Bare optical fiber; 0.9mm, 2.0mm, and 3.0mm Same
Package Size 1×2 to 1×8 smaller size than PLC More than 1×8, PLC Splitter size is smaller
Stability and Reliability Stability is better High stability not as FBT Splitter

Fiber Optic Coupler Application:

1) FTTH, LAN, PON, and Optical CATV

2) Optical fiber communication system

3) Optical fiber test equipment

4) Optical fiber sensor

5) Amplifying, Monitoring System

Wuhan Geehe Service:

1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity


2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space


3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards


4) Fast Delivery

With skilled and stable workers, all the order turnover is fast than the competitors

5) Factory Audit

We cooperate with famous brands and Japanese customers, with 15 years of factory inspection experience and be familiar with the whole inspect process by SGS

6)Warranty

All our factory products with a 12-month warranty, any comments on our products welcome to feedback to us.

Single Window 900μM OM4 1x3 Fiber Optic Cable Coupler
