8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors
Specifications
Brand Name :
Wuhan Geehe
Model Number :
GH-PLC-1X8 Fan Out
Certification :
ISO9001:2015,ISO 14001,RoHS
Place of Origin :
China Mainland
MOQ :
200 pcs
Price :
Negotiation
Payment Terms :
T/T,L/C,, Western Union, D/P, D/A
Supply Ability :
3,800 Pcs/day
Delivery Time :
3-5 working days after confirm order
Packaging Details :
Plastic box per pc with Pressure defense sponge, outer carton
Model Name :
1X8 Fiber Optic PLC Splitter
Connector Types :
SC/UPC, SC/APC, LC/UPC, LC/APC
Fusion Capacity :
8 Cores
Splitting Ratio :
1x2, 1x4, 1x8, 1x16, 1x32, 1x64,2x2, 2x4, 2x8, 2x16, 2x32, 2x36
Cable Diameter :
250um
Color Port :
2 In 8 Out
Fiber Length :
Customized Length1M, 1.5M, 2M, 2.5M, custom
Fiber Type :
G657 Grade A Optical
Port Wavelength :
1310-1550nm
Package :
Steel Tube, ABS Black Box
Description

1X8 Fiber Optic PLC Splitter With Fan-Out Kits With LC/APC Connectors

Quick Details:

PLC splitter with fan-out is mainly used for 0.9mm optical fiber where the ribbon fiber can be converted to 0.9mm optical fiber through fan-out, Fiber adapters can be provided both for the input and output ends of this kind of splitters so that they can be used directly to meet the low demand on the size of the splitter, for instance, all kinds of precision splitter insertion box and splitter wall-mounted cabinets.

Geehe provides a various of 1xN and 2xN PLC fanout splitters, including including 1x2, 1x4, 1x8, 1x16,1x32, 1x64 with fanout type PLC splitter and 2x2, 2x4, 2x8, 2x16, 2x32, 2x64 with fanout type PLC splitters.

8 Cores 1X8 Fiber Optic Plc Splitter With LC/APC Connectors

PLC Features:

  • 4, 6, 8,and 12 strand configurations
  • Two different lengths available for each type
  • Tubing colors per TIA/EIA-569-B standard
  • Provides protection to any installation
  • Easy to assemble, simple snap housing
  • 1X8 Fiber Optic PLC Splitter Device With Fan-out Kits
  • LC/APC Connectors manufacturers, suppliers, factory, wholesale, customized, buy, bulk, in stock
  • Free sample, 1:8 fan-out plc splitter

Application&Standard:

  1. FTTx systems ((FTTP, FTTH, FTTN, FTTC))
  2. CATV networks
  3. Passive Optical Networks (PON)
  4. Local Area Networks (LAN)
  5. Test equipment
  6. LAN, WAN, Metro

Specification& parameters

Parameter 1x4 1x8 1x16 1x32 1x64 2x4 2x8 2x16 2x32
Operating Wavelength(nm) 1260~1650
Port Wavelength Range (nm) 1310 ±20,1490 ±10 and 1550 ±20
Insertion Loss @1310nm/1550nm 7.1 10.5 13.6 16.8 20.5 7.4 10.8 14.5 17.5
Uniformity (dB) 0.5 0.8 1 1.2 1.8 1.2 1.5 1.8 2
PDL @ 1310/1550 nm (dB) ≤0.3
Return Loss@ 1310/1551 nm (dB) ≤-55
Input Power (mW) 250max
Operating Temperature (℃) -40~+85℃
Storage Temperature (℃) -40~+85℃
Fiber Type Corning G657A1

Fan Out PLC Splitter Package Dimensions:

WxHxD(mm) Port
40x4x4 1x4 1x8 2x4 2x8
50x7x4 1x16 1x32
60x7x4 1x32 2x32
60x12x4 1x64

Ordering Information:

PLC AAA B CC D EE FF GG
104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32 1=900µm loose 05=0.5m 10=1.0m 15=1.5m 20=2.5m 1=900µm loose 05=0.5m 10=1.0m 15=1.5m 20=2.5m SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector
Configuration Input Fiber Type Input Fiber Length Output Fiber Length Output Fiber Input Connector Output Connector

Wuhan Geehe Service:

  • Increased flexibility and control
  • Greater visibility and real-time information
  • Eliminate waste through our continuous improvement process
  • Reduced risks and disruptions
  • More than 100,000 production capacity of 5 production lines for more than 20 types of products
