Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount
Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount
Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount
Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount
Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount
Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount
Specifications
Brand Name :
Geehe Comm
Model Number :
GH- FB-Panel- 010
Certification :
ISO9001:2015,CE, ISO14001, UL
Place of Origin :
Wuhan China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
Can be Negotiated
Supply Ability :
500 pcs/ per day
Delivery Time :
Within 7-9 working days after confirm order
Packaging Details :
Individual inner paper box, paper outer cartons
Model Name :
12 Cores Fiber Optic PLC Splitter
Structure :
19'' Rack Mounted
Rack Material :
Zinc-plated Cold Roll Steel Sheet
Rack Color :
Black, White, Grey,or OEM
Height :
1U, 2U, 3U, 4U, 8U
Ports :
6, 12, 24, 48, 72, 96, 144
Connector :
SC LC FC ST
Thickness :
0.8mm,1.0mm, 1.2mm
Max. Fiber Cores :
24
2U Dimensions (Hxwxd) :
48.2×27.8×88mm
Description

Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount

Fiber Splitter Sell Points:

1) Made by cold roll steel, electrostatic powder spraying

2) Easy to open and close by using the button

3) Field-termination with high-accessibility sliding and tilting drawers

4) With PVC transparent door at front and back, easy to monitor

5) Can adjust depth when fixing the patch panel into the cabinet

6) Installation with tool-less removable drawers and lightweight housings

7) Port identification with clear visible labeling

8) 12 Fibers fanout for easy installation

Fiber Optic PLC Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. Fiber Optic PLC Splitter features small size, high reliability, wide operating wavelength range, and good channel-to-channel uniformity, and Fiber Optic PLC Splitter is widely used in PON networks to realize optical signal power splitting.

Geehe provides the whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE requirements.

Connectors available: SC,LC,FC, MPO/MTP, E2000, MU etc.

Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount

​Benefit& Features:

  • Low insertion loss and low PDL
  • Various coupling ratio
  • Environment stable
  • Single-mode and multimode available
  • High Reliability and Stability
  • High Channel counts
  • Wide wavelength range
  • Customized packaging and configuration

Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount

Wall Mount Application:

  • FTTx Construction
  • Fiber Optical communication system
  • Fiber Optical access networks
  • Fiber Sensor
  • Fiber CATV networks
  • Local area networks

Single Mode SC UPC Fanout 12 Cores Fiber Optic PLC Splitter 0.9mm Rack Mount

Specificaiton&Technology Parameters :

Parameter 1x4 1x8 1x16 1x32 1x64 2x4 2x8 2x16 2x32
Operating Wavelength(nm) SDWC:1310&1550；STWC:1310,1490&1550
Port Wavelength Range(nm) 1310 ±40,1490 ±10 and 1550 ±40
Insertion Loss @1310nm/1550nm 7.1 10.5 13.6 16.8 20.5 7.4 10.8 14.5 17.5
Uniformity (dB) 0.6 1 1.6 2 1.8 0.8 1.2 1.8 2.2
PDL@ 1310/1550 nm (dB) ≤0.3
Input Power (mW) 250max
Operating Temperature (℃) -40~+85℃
Storage Temperature (℃) -40~+85℃
Fiber Type Corning G657A1, 900μm, 2mm, 3mm Loose Tube
Dimensions(L×W×H) (mm) 100×80×10,141×115×18, On request

* The above specification exclusive connector

19 Inch Rack Specification:

19 Inch Rack LGX
Configuration 1U 2U 1U 2U
Packing Dimensions(mm) 482.6×278×44 482.6×278×88 129×125×29 129×125×58
Installation Dimensions (mm) 462.7×11.0(4-Φ6) 462.7×27.5(6-Φ6) 118(2-Φ6) 118×29.2(2-Φ7)

Ordering Information:

WBC- X- X2- 35- XX- X- XX- XX- X
P: Premium
A: Grade A
X: Follow Customer's Requirements		 13:1x3
14:1X4
…
232:2 X32		 35:1310/1550nm 01: 01:99
02: 02:98
……
50: 50:50		 1:1 m
x: Follow Customer's Requirements		 25:250μM Fiber
09:900μM Loose Fiber		 SC: SC/UPC SA: SC/APC
00:no connect		 D:D
1U: J1
2U: J2
Grade Port Number Operation Wavelength Coupling Ratio Fiber Length Fiber Type Connector Type Dimension

Wuhan Geehe Service:

1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity


2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space


3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards


5) High-quality Wire Rod
Excellent PVC wire, good strength, and tenacity, long lifespan

6) Free Samples

Welcome to contact us to get Free Samples, Summer:+86 13429864799
