Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
Specifications
Brand Name :
Geehe Comm (OEM&ODM)
Model Number :
GH-AD-HY59
Certification :
ISO9001:2015, ISO:14001:2015,RoHS, UL,CE
Place of Origin :
China Mainland
MOQ :
1pc
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
3,000 pcs/per day
Delivery Time :
Within 7-9 working days after receive the deposit
Packaging Details :
Plastic box per pc with pressure defense sponge, outer carton Or OEM
Model Name :
Fiber Optic Hybrid Adapter FC-SC simplex
Mode Type :
Simplex, Duplex
Adapter Insert Material :
Zirconia/Ceramic, Metal
Housing Material :
Metal, Plastic
Connector :
FC Male to SC Female
Fiber Counts :
Simplex
Color :
Green
Durability :
>1000 mating times
Operating Temperature :
-40~75℃
Adapter Mounting Type :
With Flange
Description

Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC simplex


1. Product Overview:

Multimode SC to FC Simplex Coupler - This item provides the link between Fiber networking devices. This coupler allows for connecting of similar connector types for short-distance networks at high speeds. Multimode fiber optical products are used for short-distance signal transmission. PI Manufacturing provides a wide selection of fiber adapters at competitive prices. These adapters allow you to connect various types of optic fibers together.

Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex

2. Optical Cable Adaptor Feature and Benefits:

  • Connection Type: SC to FC
  • Housing: Metal
  • Telecommunication: Simplex
  • Data Connection: Multimode
  • Sleeve: Polymer
  • Style: Square Flange
  • Hybrid SC Female to FC Female

3. Fiber Optic Adapter Applications:

  • Designed for fiber optic Connectivity
  • Telecommunication networks
  • Premise installations
  • LAN and WAN
  • FTTX
  • Handle bandwidth-intensive applications


4. Optic Adapter Specification & Technology Parameters:

Item Value Unit
Sleeve Material Ceramic /
Insertion Loss Male Typ. ≤ 0.5 dB
Min. ≤ 0.2 dB
Female Typ. ≤ 0.3 dB
Min. ≤ 0.2 dB
Return Loss UPC ≥50 dB
APC ≥60 dB
PC ≥35 dB
Insertion Loss Max. 0.2 dB
∆ IL Uniformity ＜0.2 dB
Durability (1000 times) ＜0.3 dB
Proof Test 40N,10 minute N
Insertion And Withdrawal Force ≤19.6N N
Operating Temperature -25~+70 ℃
Storage Temperature -25~+70 ℃
Protocol Standards IEC60874-10/61300/TIA/EIA568



5. Ordering Information:

OFC -X -XX -XX -XX -X -X
S: Simplex
D: Duplex		 SC
FC
ST
LC
MU		 APC
UPC
PC		 Z: Zirconia ceramic P: Phosphor Bronze W: With Flange
N: No Flange		 W: With shutter
N: No shutter
Fiber Mode Connector Type Connector Type Sleeve Flange Type Shutter Type



6.More Options Optic Adapters:

Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex

7. Wuhan Geehe Comm Service:

1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity


2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space


3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards

4) ISO9001:2015 Certification by SGS

All products have passed ISO9001:2015 System and reached Telcordia GR-326-Core, GR1209/1221.

Multimode Polymer Sleeve Metal Flange Fiber Optic Hybrid Adapter FC-SC Simplex
