10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord
10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord
10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord
10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord
Specifications
Brand Name :
Geehe
Model Number :
GH-OP-DP-0024
Certification :
ISO9001:2015 by SGS, UL, CE
Place of Origin :
Hubei,China
MOQ :
100 pcs
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
280,000 pcs/ month
Delivery Time :
With 7-9 working days after confirmed the order
Packaging Details :
PE bags with thick outer cartons, follow customers' requirements
Model Name :
Fiber Optic Cables
Cable Diameter :
1.8mm,2.0mm,3.0mm
Fiber Counts :
2 Cores
Polishing :
UPC,APC,PC
Jacket Material :
PVC/LSZH/OFNR
Cable Length :
1M,2M,3M...customize
Cable Dimensions :
3.0mm
Jacket Color :
Yellow
Fiber Type :
Multimode 50/125
Attenuator :
1310 nm: 0.25 dB/km or at 1550 nm: 0.35 dB/km
Description

10Gb 40Gb OFNP Plenum-Rated Multimode Duplex 50/125 OM3 Fiber Optic Cables

1.Fiber Patch Cord Basic Introduction:

As a high - level OEM manufacturer of Fiber optic assemblies, Geehe has a dedicated area specifically for manufacturing of all our fiber optic cables, assemblies, patch cords, fiber trunk, and fiber jumpers. The reliability and peak performance of fiber optic patch cords hinge on a clean environment. Our facility is designed to prevent the most common sources of fiber optic contamination.

Geehe PM Patchcords adopts the integration of material processing, the craft is advanced with extinction ratio stable insertion loss low.

High-Level OEM service for Brands/ Brand manufacturers.

10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord



2.Fiber Optic Patch Cord SC To SC

  • Low optical power loss
  • Small, light, high dense connection
  • Standard exact plastic material
  • High credibility and stability
  • Good in repeatability and exchangeability
  • Mini bending radius: 25mm
  • Maximum short-term tension load: 50N
  • Low Polarization Dependent Loss
  • High mechanical strength, superior fatigue
  • Connector configurations include – LC/LC, LC/SC, LC/ST, SC/SC, ST/SC and ST/ST

10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord

3.SC To SC Patch Cord Application:

  • Testing equipment
  • FTTX+LAN
  • Optical fiber CATV
  • Optical communication system
  • Telecommunication


4.Specification&Technology Parameters

Parameters Value
Connector Type LC/UPC,LC/UPC
Center Wavelength(nm) 1310 or 1550
Max.Insertion Loss(dB) 0.3
Min.Extinction Ratio(dB) 23
Min.Return Loss(UPC) (dB) 50
Min.Return Loss(APC) (dB) 60
Key Orientation Slow Axis
Axis Alignment(deg) ±3
Operating Temperature(℃) -20~+70
Storage Temperature(℃) -40~+85
FIber Type PM Panda Fiber


* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.

5. Fiber patch cord SC Specification& Technology Parameter​:

Parameter Unit Index
End-Face Type PC UPC APC
IL dB SM: ≤0.3；MM ≤0.1
Repeatability dB ≤0.1
interchangeability dB ≤0.2
RL SM dB ≥50 ≥50 ≥50
MM dB ≥36(Without APC connector)
Mating Times ＞1000
Operating Temperature ℃ -40~ +80


* EX:OFC-D-LA-LA-09-1-1.0

6.Ordering Information:

10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord


7. Geehe Service

  • Provide the highest quality of products
  • Continuous improvement; accepting new challenges
  • Innovating new processes, and creating new products for the benefit of our customers
  • Consultative service and strive to ensure a positive and productive experience
  • Efficient use of all transportation modes and transit times
  • Greater visibility and real-time information
  • Free samples for testing
  • Factory inspection experience
  • Fast delivery for all customer orders

10Gb 40Gb OFNP Multimode Duplex 50/125 OM3 Patch Cord
