Single Mode OS1 Simplex 2 Meters Fiber Patch Cables E2000 To LC
Single Mode OS1 Simplex 2 Meters Fiber Patch Cables E2000 To LC
Single Mode OS1 Simplex 2 Meters Fiber Patch Cables E2000 To LC
Single Mode OS1 Simplex 2 Meters Fiber Patch Cables E2000 To LC
Specifications
Brand Name :
Geehe
Model Number :
GH-OP-DP-009
Certification :
ISO9001:2015 by SGS, UL. RoHS
Place of Origin :
Wuhan China
MOQ :
200 pcs
Price :
Negotiation
Payment Terms :
T/T, D/P, D/A,, MoneyGram,Cash, Western Union
Supply Ability :
300,000 pcs/ month
Delivery Time :
With 7-9 working days after confirmed the order
Packaging Details :
PE bags with thick outer cartons,follow customers' requirements
Model Name :
Fiber Patch Cables E2000 To LC
Cable Diameter :
1.8mm,2.0mm,3.0mm
Fiber Counts :
2 Cores
Polishing :
UPC,APCM,PC
Jacket Material :
PVC/LSZH/OFNR
Cable Length :
1M,2M,3M...customize
Cable Dimensions :
3.0mm
Jacket Color :
Yellow
Fiber Type :
Single Mode, Multimode
Attenuator :
1310 nm: 0.25 dB/km or at 1550 nm: 0.35 dB/km
Description

Single Mode OS1 Simplex 2 Meters Fiber Patch Cables E2000 To LC



1. Fiber Patch Cables Basic Introduction:

Fiber optic cabling is the medium of choice for longer distance and challenging cabling runs. These cables are thinner than copper patch cords and immune to EMI (Electromagnetic Interference) making them perfect for riser runs and uplink cables.

Multimode & Single Mode Fiber Optic Patch Cables Fiber optic patch cables connect fiber optic patch panels and high-speed network devices. Complex patch cables are fully tested to ensure reliable performance in critical applications.

Available in single-mode fiber and multimode fiber cable, simplex or duplex, and a variety of standard fiber optic connectors.

2. Fiber Patch Cables Features & Benefits:

  1. OS1 9/125 Single Mode Fiber
  2. Zipcord style plenum rated construction
  3. LC duplex to LC duplex Connectivity
  4. 1, 2, 3 meters standard lengths, other lengths available on request
  5. Yellow-colored jacket designates Single Mode

3. Fiber Patch Cables Application:

  1. 10/100/1000/10G/40G/100G Ethernet Fiber Patching
  2. A/V, Data, Control, Phone Support
  3. TELCO, HD Security, High Bandwidth Signals
  4. Economical solution to field termination
  5. Always patch out to equipment! It is the standard


4. Specification&Technology Parameters

Parameters Value
Connector Type LC/UPC,LC/UPC
Center Wavelength(nm) 1310 or 1550
Max.Insertion Loss(dB) 0.3
Min.Extinction Ratio(dB) 23
Min.Return Loss(UPC) (dB) 50
Min.Return Loss(APC) (dB) 60
Key Orientation Slow Axis
Axis Alignment(deg) ±3
Operating Temperature(℃) -20~+70
Storage Temperature(℃) -40~+85
FIber Type PM Panda Fiber


* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.

5. Fiber patch cord SC Specification& Technology Parameter​:

Parameter Unit Index
End-Face Type PC UPC APC
IL dB SM: ≤0.3；MM ≤0.1
Repeatability dB ≤0.1
interchangeability dB ≤0.2
RL SM dB ≥50 ≥50 ≥50
MM dB ≥36(Without APC connector)
Mating Times ＞1000
Operating Temperature ℃ -40~ +80


* EX:OFC-D-LA-LA-09-1-1.0

6. Ordering Information:

OFC -X -XX -XX -XX -X -X
S: Simplex
D: Duplex		 SA:LC/APC SC:LC/UPC SP:LC/PC SA:LC/APC SC:LC:UPC SP:LC/PC 09:0.9mm 20:2.0mm 30:3.0mm 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others 0.5:0.5m
1.0:1.5m
10:10.0m
Fiber Mode Connector Type Connector Type Cable Diameter Flange Type Fiber Length
