LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
Specifications
Brand Name :
Geehe Comm (OEM)
Model Number :
GH-OP-MM-0038
Certification :
ISO9001:2015,CE,RoHS,UL
Place of Origin :
Hubei,China
MOQ :
100 pcs
Price :
Negotiation
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
520,000 pcs/ month
Delivery Time :
With 5-7 working days after confirmed the order
Packaging Details :
PE bags with thick outer cartons,follow customers' requirements
Model Name :
Uniboot 5M Duplex Fiber Optic Cable
Fiber Counts :
Duplex
Fiber Type :
50/125 LSZH 2.0mm OD Fiber Patch Cable, OM3 MM Duplex LC-LC Fiber Optic Cables
Sheath Material :
OFNR Riser
Connectors :
LC to LC
Cable Length :
0.5m/1m/1.5m or Customized
Endface of The Connector :
PC/UPC/APC
Diameter of The Cable :
0.9/2.0/3.0/4.8/7.0
Fiber Color :
Yellow/orange/Aqua/Red customerized
Impact Cycle :
1500
Description

LC to LC OM3 10Gb Uniboot 5M Duplex Multimode Fiber Optic Cable

1. Fiber Patch Cord Basic Introduction:

The Uniboot patch cord places both simplex fibers into one jacket while still terminating into a duplex LC or SC connector. Typical fiber optical cables use a zip-cord approach, which means that both fibers are jacketed separately. The typical size of the jacket is 3mm and on a zip cord, this would be 6mm in width. With the creative design of the Uniboot now the entire cable is just 3mm which is a space savings of 50%.

Termination: LC Uniboot, SC Uniboot, LC, SC, FC, ST, MTRJ, MTP®/MPO (Single-mode polishes UPC and APC)


Jacket material: Plenum, Riser, and LSZH

Fiber types: Laser optimized 10G OM3, OM2 in 50mm and 62.5, Single Mode

2. Uniboot Fiber Optic Patch Cord Benefit & Features:

  1. Aqua Blue 50/125 Riser-Rated jacket
  2. Uniboot Connector- you can reverse the polarity without any tools
  3. High-Quality Duplex LC Connectors on each end.
  4. 10 GB OM3 rated
  5. ROHS Compliant
  6. Clean and Scratch-Free End Face
  7. Pull-Proof Jacket
  8. Immune to electrical interference
  9. ROHS Compliant

LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc

3. Uniboot Patch Cord Applications:

  • Telecommunication Networks
  • Fiber Optic Communication Networks
  • Optical Access Network
  • Data Processing Networks

LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc

4. Specification&Technology Parameters

Construction
Fiber Count 2- Fiber Round
Cable Jacket Ratings Plenum (OFNP)
Low Smoke Zero Halogen (LSZH)
Fiber Types Singlemode: OS2 9/125um
Multimode: OM3 50/125um OM4/4+50/125um OM5+ 50/125um
Connector Types Duplex LC Uniboot
Jacket Color OS1/OS2: Yellow OM3: Aqua OM4: Aqua OM4+:Aqua OM5+:Lime Green
Physical Properties
Cable outside diameter (OD) 2.0mm
Bend radius (min) 40mm
Connector durability 500 cycles
Bend radius (min)(Long- term) 20mm (40mm)
Optical Properties
Connector insertion loss MM: 0.15dB max (Optimized IL) 0.10dB max (Ultra-low IL) 0.25dB max (Optimized IL)
SM: 0.25 dB max ( Optimized IL)
Connector return loss 26dB min (MM) 55dB min (SM) 65dB min (SM/APC)
Environmental Properties
Storage and shipping temperature -40℃-+70 ℃
Operating and installation temperature -40℃-+70 ℃

5. Ordering Information

Code Fiber Type Cable Type Jacket Material Color Length (m)
P 3 OM3 AR2 Round 2mm L LSZH Y Yellow 1
4 OM4 AX2 Round 2.4mm R OFNR A Aqua 2
7 G.657A1 P OFNP E Erika Violet 3
8 G.657A1 5
10

Legacy ordering information

Connector End Mode Cable Configuration Cable Colour Cable Diameter Cable Length (m)
LC to LC 9 OS1/OS2 D Duplex Y Yellow 2.4mm 1
7A1 G.657A1 DR Duplex Riser A Aqua 3.0mm 2
7A2 G.657A2 DP Duplex Plenum P Purple 3
OM3 OM3 5
OM4 OM4 10


6. Options Available

-- LC Custom fiber optic jumper options include.
-- LC/PC (Physical Contact) Polish
-- LC/UPC (Ultra Physical Contact) polish
-- LC/APC (Angled Physical Contact) polish

Jacket: Riser (OFNR), Plenum (OFNP), Low Smoke Zero Halogens (LSZH), PVC

Diameter: 0.9mm (900µm), 1.6mm, 1.8mm, 2.0mm, 3.0mm

Jacket Colors: Aqua, Orange, Green, Red, Blue, Gray, Black, Yellow
LC Multimode 62.5/125µm MMF Fiber (Corning Fiber Optic Cable)
LC Multimode 50/125µm MMF OM2 Fiber (Corning Fiber Optic Cable)
LC Multimode 50/125µm MMF OM3 10Gb Laser Optimized Fiber (Corning Fiber)
LC Simplex cables or LC Duplex Cables are also available in optional colors.
LC Standard boot, LC 45° angled boot, LC 90°angled boot, or short boot options.
Corning Fiber Optic Cable, or Fiber One Fiber.
Call us today to speak with one of our qualified salespeople to help answer any questions.

LC To LC OM3 10Gb Uniboot 5M Duplex Patch Cord Multimode Lc Lc
