1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter
1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter
1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter
1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter
Specifications
Brand Name :
Wuhan Geehe
Model Number :
GH- FB-Panel- 009
Certification :
ISO9001:2015,CE, ISO14001,CE
Place of Origin :
Hubei,China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
Can be Negotiated
Supply Ability :
500 pcs/ per day
Delivery Time :
Within 7 working days after confirm order
Packaging Details :
Individual inner paper box, paper outer cartons
Model Name :
Fiber Optic PLC Splitter
Structure :
19'' Rack Mounted
Rack Material :
Zinc-plated Cold Roll Steel Sheet
Rack Color :
Black, White, Grey,or OEM
Height :
1U, 2U, 3U, 4U, 8U
Ports :
6, 12, 24, 48, 72, 96, 144
Connector :
SC LC FC ST
Thickness :
0.8mm,1.0mm, 1.2mm
Max. Fiber Cores :
24
2U Dimensions (Hxwxd) :
48.2×27.8×88mm
Description

1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter

2U Patch Panel Sell Points:

1) Made by cold roll steel, electrostatic powder spraying

2) Easy to open and close by using the button

3) Field-termination with high-accessibility sliding and tilting drawers

4) With PVC transparent door at front and back, easy to monitor

5) Can adjust depth when fixing the patch panel into the cabinet

6) Installation with tool-less removable drawers and lightweight housings

7) Port identification with clear visible labeling

Fiber Optic PLC Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. Fiber Optic PLC Splitter features small size, high reliability, wide operating wavelength range, and good channel-to-channel uniformity, and Fiber Optic PLC Splitter is widely used in PON networks to realize optical signal power splitting. Geehe provides the whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE requirements.

​Benefit& Features:

  • Low insertion loss and low PDL
  • Various coupling ratio
  • Environment stable
  • Single-mode and multimode available
  • High Reliability and Stability
  • High Channel counts
  • Wide wavelength range
  • Customized packaging and configuration

1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter

Wall Mount Application:

  • FTTx Construction
  • Fiber Optical communication system
  • Fiber Optical access networks
  • Fiber Sensor
  • Fiber CATV networks
  • Local area networks
  • Datacenter

1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter

Specificaiton&Technology Parameters :

Parameter 1x4 1x8 1x16 1x32 1x64 2x4 2x8 2x16 2x32
Operating Wavelength(nm) SDWC:1310&1550；STWC:1310,1490&1550
Port Wavelength Range(nm) 1310 ±40,1490 ±10 and 1550 ±40
Insertion Loss @1310nm/1550nm 7.1 10.5 13.6 16.8 20.5 7.4 10.8 14.5 17.5
Uniformity (dB) 0.6 1 1.6 2 1.8 0.8 1.2 1.8 2.2
PDL@ 1310/1550 nm (dB) ≤0.3
Input Power (mW) 250max
Operating Temperature (℃) -40~+85℃
Storage Temperature (℃) -40~+85℃
Fiber Type Corning G657A1, 900μm, 2mm, 3mm Loose Tube
Dimensions(L×W×H) (mm) 100×80×10,141×115×18, On request

* The above specification exclusive connector

19 Inch Rack Specification:

19 Inch Rack LGX
Configuration 1U 2U 1U 2U
Packing Dimensions(mm) 482.6×278×44 482.6×278×88 129×125×29 129×125×58
Installation Dimensions (mm) 462.7×11.0(4-Φ6) 462.7×27.5(6-Φ6) 118(2-Φ6) 118×29.2(2-Φ7)

Ordering Information:

WBC- X- X2- 35- XX- X- XX- XX- X
P: Premium
A: Grade A
X: Follow Customer's Requirements		 13:1x3
14:1X4
…
232:2 X32		 35:1310/1550nm 01: 01:99
02: 02:98
……
50: 50:50		 1:1 m
x: Follow Customer's Requirements		 25:250μM Fiber
09:900μM Loose Fiber		 SC: SC/UPC SA: SC/APC
00:no connect		 D:D
1U: J1
2U: J2
Grade Port Number Operation Wavelength Coupling Ratio Fiber Length Fiber Type Connector Type Dimension

Wuhan Geehe Service:

1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity


2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space


3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards


5) High-quality Wire Rod
Excellent PVC wire, good strength, and tenacity, long lifespan

6) Free Samples

Welcome to contact us to get Free Samples, Summer:+86 13429864799

1×16 Rack Mount 1U SC/APC Fiber Optic PLC Splitter
