980/1550nm Wideband WDM Combiner With FC Connector
980/1550nm Wideband WDM Combiner With FC Connector
980/1550nm Wideband WDM Combiner With FC Connector
980/1550nm Wideband WDM Combiner With FC Connector
Specifications
Brand Name :
Geehe Comm
Model Number :
GH-OS-WDM-0018
Certification :
ISO9001:2015, RoHS,Telcordia GR-1209/1221-Core
Place of Origin :
Wuhan, China
MOQ :
200 pcs
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union.Cash, D/A, D/P, Paypal,Ali pay
Supply Ability :
900pcs/ day
Delivery Time :
With 7-9 days after confirmed the order
Packaging Details :
Plastic box per pc with pressure defense sponge, outer carton
Module Name :
980/1550NM Wideband Couplers
Port Type :
1×2
Fiber Type :
Fiber all ports or SM fiber
Jacket :
250um or 900nm or others
Connectors :
With FC Connectors
Pigtail Length :
1M,1.5M or customized
Common Pass port :
PM980,PM1310 or PM1550
Option Channel :
2, 4, 8 , 16, 18 ,36, 48 Channels
Operating Wavelength :
980~1620 nm
Package :
Original Carton Package; As customers' requirement
Description

980/1550nm Wideband WDM Combiner with FC Connector


Basic Information:

Geehe manufactures a broad range of couplers and wavelength Division Multiplexers (WDM's) designed to distribute traffic and
increase capacity on fiber networks without installing additional cable. Geehe developed and improved ultra-reliable fused taper machines with a
computer-controlled fabrication station. Geehe offers components that feature low insertion loss, excellent stability, and long-term reliability. All couplers are available in a variety of packaging styles and performance levels to maximize product compatibility with specific network requirements.


Custom configurations are available, and Geehe's technical staff can assist you in designing a unit to meet your specific requirements.

980/1550nm Wideband WDM Combiner With FC Connector.

WDM Benefit&Features:

980/1550nm Wideband WDM Combiner With FC Connector

Fused WDM Benefit&Features:

* GR-1209-CORE Requirements for passive optic components

* GR-1221-CORE Reliability assurance requirements for passive optical components

* GR-326-CORE Requirements for single-mode optical connectors sand jumpers assemblies

* TIA-604 Fiber optic connector interpretability standard

* ROHS Directive on the restriction of hazardous substances

980/1550nm Wideband WDM Combiner With FC Connector

1×2 Fused WDM Applications:

  • Passive Optical Network (PON)
  • Optical Amplifiers
  • Optical Access Networks/LAN
  • Monitoring Systems
  • Optical Fiber Sensor
  • Medical OCT Devices
  • Datacenters
  • Telecommunications
  • CATV and LAN
  • Monitoring of Networks

980/1550nm Wideband WDM Combiner With FC Connector

Specifications& Technology Parameters:

Parameter 980/1550nm WDM or 1060/1550nm WDM 1310/1550nm WDM 1480/1550nm WDM
Fiber Type(dB) Corning HI1060flex or OFS BF05635-02 SMF-28e
Operating Wavelength(nm) 980 & 1550 1060 & 1550 1310 & 1550 1480 & 1550
Operating Bandwidth(nm) ±10/20 ±15 ±15
Grade P A P A P A P A
Insertion Loss(dB) ≤0.15 ≤0.25 ≤0.30 ≤0.40 ≤0.2 ≤0.3 ≤0.3 ≤0.35
Isolation(dB) ≥20 ≥18 ≥20 ≥18 ≥25 ≥18 ≥25 ≥18
PDL(dB) ≤0.05 ≤0.1 ≤0.05 ≤0.1 ≤0.05 ≤0.1 ≤0.1 ≤0.1
Directivity(dB) ≥55
Operating Temperature(℃) -40 ~ +85


* The above specification is excluding the connector
* Other specifications can be made on customer requires


Ordering Information:

WDM- N- XX- XX- X- XX- XX- X
95:980&1550nm 135:1310&1550nm 65:1060&1550nm 45:1480&1550nm 01: :SMF-28e
02: HI1060flex,
03: OFS BF05635-02		 1:1m
X:customization		 25:250μM Fiber
09:900μM loose Fiber 20: 2mm cable
30: 3mm cable		 SC:SC/UPC
SA:SC/APC
......
00:No connector		 A: A
B: B
C: C
Grade Operation Wavelength Fiber Type Fiber Length Pigtail Type Connect Type Dimension

WDM Cable Types:


1. Single-mode fibers allow one mode to propagate.
2. Multimode fibers support the propagation of multiple modes.
3. Wavelength range is the range of wavelengths the WDM will operate in.
4. Bandwidth, also called channel spacing, is the size of the windows in nm.
5. Channel spacing is the center-to-center difference in frequency between neighboring channels. Two hundred GHz corresponds to .4 nm spacing, 100 GHz corresponds to .2 nm spacing, and 50 GHz corresponds to .1 nm spacing.
6. Number of channels is the number of channels the device has to send information. This number can range from 4 to 160 with design enhancements adding more channels.
7. Insertion loss is the attenuation caused by the insertion of wavelength division multiplexers (WDM) in an optical transmission system.
Polarization-dependent loss is the maximum deviation in insertion loss across all input polarization states.

Wuhan Geehe Comm Service:

-- Continuous improvement; accepting new challenges
-- Innovating new processes, and creating new products for the benefit of our customers

-- Free samples for testing

-- Factory inspection, also accept the third party inspect

-- Younger Team

980/1550nm Wideband WDM Combiner With FC Connector
