Easy Installation 1U SC UPC Fiber Optic Patch Panel Rack Mount With SC/UPC

Basic Information:

The patch panels feature adjustable mounting brackets, numbered adaptor ports and a range of rear panel knock-outs to suit all common cable gland sizes. Sliding draw versions for access inside the panel are also available.

Singlemode SC/APC Fibre Optic Patch Panels are supplied fully loaded and complete with internal splice management kit. Unloaded panels, bulkhead adaptors and splice kits can also be supplied.

Fiber Patch Panels 24 port Benefit& Feature:

1. 1.5mm cold rolled steel
2. Front saddles pivot for improved patch cord routing
3. Bend radius guides minimise macro bending
4. Fully assembled loaded or empty
5. 175 adapter interfaces available including ST, SC, FC, LC
6. Splice capacity up to max 48 fibers with splice trays loaded
7. Easy slide in and out
8. Recessed adaptors for improved fibre management
9. No exposed screws
10. Built-in strength member tie positions
11. High-quality finish
12. Modular design for easy organization

Fiber Patch Panels 24 port Application:

1) Telecommunications networks
2) FTTH
3) LAN, WAN, CATV netoworks
4) Active device termination
5) CCTV
6) IPTV

Specificaiton&Technology Parameters :

* The above specification exclusive connector

19 Inch Rack Specification:

Ordering Information:

Wuhan Geehe Service:

1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity

2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space

3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards

4) High-quality Wire Rod
Excellent PVC wire, good strength, and tenacity, long lifespan
