High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
High return loss, low insterion loss FC / PC Fiber Optic Patch Cord
Specifications
Place of Origin :
Shenzhen , China
Brand Name :
CY COM
MOQ :
20
Packaging Details :
PE bag
Delivery Time :
3-15 days
Payment Terms :
L/C,T/T,Western Union payments for offline orders.
Supply Ability :
1 million connector / month
Certification :
ISO9001:2015 , RoHS
Product Name :
Fiber Optic Patch Cord
Ferrule End-face :
PC, UPC, APC
Core :
Simplex, Duplex
Cable Diameter :
Ф3.0mm, Ф2.0mm, Ф0.9mm
Cable Length :
1, 2, 3 meter or customized
Cable Type :
PVC, LSZH, OM3, OFNR, OFNP
Description

High return loss, low insterion loss FC / PC Fiber Optic Patch Cord

FC stands for Fixed Connector. FC Connectors are generally constructed with a metal housing and are nickel-plated.

Features:

High return loss
Low insterion loss
Telcordia style boots
Compiance with TIA/IEA, IEC, Rohs

Application:

1.FTTH , CATV, LAN, MAN, WAN, Test &Measuremen
2.Video transmission , Data transmission
3.Active Device Termination
4.Premise Installations
5.Telecommunication and Data processing Networks
6.Industrial, medical & military
7.Systems Integration for Long Haul, Metro and Access Network
Specification PC(Standard) PC(Standard)
IL (Insertion Loss) ≤0.3dB ≤0.2dB
RL (Return Loss) ≥50dB ≥55dB
Operating Temperature -40℃ to 75℃
Durability ≤0.1dBtypical change, 500matings
Available Wavelength SM=1310&1550nm

Ordering Information:

  1. Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
  2. Ferrule End-face: PC, UPC, APC
  3. Core Type: Single mode(SM: 9/125um), Multimode(MM: 50/125um or 62.5/125um)
  4. Core quantity: Simplex(SX), Duplex(DX)
  5. Cable diameter: 0.9mm, 2.0mm, 3.0mm
  6. Cable Length: 1M, 2M, 3M....
  7. Cable type: PVC, LSZH, OM3, OFNR, OFNP, Armoured...
  8. Color: Yellow, Orange, Green, Red, Blue.....

High return loss, low insterion loss FC / PC Fiber Optic Patch CordHigh return loss, low insterion loss FC / PC Fiber Optic Patch CordHigh return loss, low insterion loss FC / PC Fiber Optic Patch CordHigh return loss, low insterion loss FC / PC Fiber Optic Patch CordHigh return loss, low insterion loss FC / PC Fiber Optic Patch Cord
