Fan Out LC / UPC pigtail fiber optic 12 Core With High Tensile Strength

Company Information
More than 10 years experience
Export more than 30 countries
Certified with ISO9001:2008,ROHS
Free samples can be supplied for your test

There are 4core, 6core, 8core, 12cores and 24core distribution fan out pigtails.

12core distribution fan out fiber optic cable assemble SC, FC, ST, LC connectors, suitable for ODF, fiber cross cabinet and other communication equipment. It is with high strength aramid yarn ensure high tensile strength and long term stability during transmission.

Multi cores pigtail, is with small outer diameter cable, light weight, flame-retardant, soft and easy to install and operate.

The pigtail contains 12cores and we can assemble various types of connectors upon customer request. Single mode cable color is yellow, multimode cable color is orange. Other colors options are also available. LSZH or flame-retardant material are also can be chosen.

Material

Fiber Type: SM (9/125um), OM1(62.5/125um), OM2(50/125um), OM3, OM4

Connector Type: FC, SC, ST, LC, MU, MTRJ, MPO, E2000, SMA, FDDI, D4, DIN

End face type: UPC, APC

Cores: simplex, multi core pigtails (6pack, 8pack, 12pack, 24pack, 48pack)

Cable Jacket: PVC, LSZH, OFNR, OFNP

Applications
Optical fiber communication systems
Optical fiber data transmission
Building network access
Cabling system, ODF
Gigabit Ethernet;
Active device termination;
Telecommunication networks; Video;
Multimedia;
Premise installations;
Local area networks;
FTTH and FTTX applications;
CATV.

Features
Good durability
Good exchangeability
High temperature stability
Low insertion loss and back reflection loss
Superior Quality Standard PC/UPC/APC Polishing
Standard: Telcordia GR-326-CORE, TIA/EIA and IEC

Specifications

Ordering Information
