OM4 Full Flange Compact MPO Multimode Optical Cord Adapter 0.2dB / 0.3dB
OM4 Full Flange Compact MPO Multimode Optical Cord Adapter 0.2dB / 0.3dB
Specifications
Brand Name :
FOCABLE
Model Number :
MPO Fiber Optic Adapter
Certification :
RoHS Compliant, ISO Certificate
Place of Origin :
China
MOQ :
100PCS
Supply Ability :
90000PCS/Month
Packaging Details :
50PCS/Blister Box
Sleeve material :
Bronze Sleeve, Zirconia Ceramic Sleeve
Adapter :
FC, SC, ST, LC, MTRJ, MPO, E2000
Cores :
Simplex, Duplex, Quad
Material :
Metal, Plastic
Cap Color :
White, Red
Mode :
Singlemode, Multimode
Description

Fiber Optic Adapter MPO Multimode OM4 Full Flange Compact Size​

MTP/MPO connectors utilize precision molded MT ferrules, with metal guide pins and precise housing dimensions to ensure fiber alignment when mating. The MTP can be mass terminated in combinations of 4,8 or 12 fiber ribbon cables. The MTP/MPO adapter comes standard in black, other colors can be available upon request.

This MTP Connector Adapter has a SC Footprint, Full Flange, is violet, and comes with 2 Dust cap. The adapter body is made of Polyethermide, the spring clip is made of stainless steel, and the dust cap is made of polycarbonate, all to reduce the potential for debris generation. This adapter is configured with an Opposed Key Orientation, meaning that the connectors are key-up to key-down.

This adapter works for any MTP Connector from 4 fiber to 12 fiber. Widely used in trunk cabling and casettes, this adapter meets appropriate standards and is perfect for your paralell optics and MTP Adapter needs.

Specifications

Insertion loss (Typical/Max): 0.2dB/0.3dB

Retention Force: 200 - 600 grams

Durability (500 Matings): 0.15dB max

Operating temperature: -40 ~ +80℃

Storage temperature: -40 ~ +80℃

Features

Precision molded MT ferrule

High precision guide pins for exact alignment

Compact design, up to 12 fiber ribbons

IEC 61754-7 Compliant

Telcordia GR-1435-CORE compliant

Polishing does not require diamond film

Applications

Networking

Data communication centers

Optical electrical modules

Optical switch and routers

PC cards and patch panels

Parallel optic transceiver interconnection

Hubs and servers

Line cards
