Fiber Optic Adapter LC SM Simplex Zirconia Ceramic Sleeve High Stability

Optical adapters (couplers) are designed to quickly connect two fiber optic patch cables together within a fiber optic networking system. Choose between single mode and multimode functions for simplex or duplex fiber cables. These fiber optic couplers are available in straight or hybrid configurations with ST, SC, LC, or FC connectors. Pair with Fiber Optic Patch Cables to ensure reliable network links. Also accompany with any of Fiber Optic Transceivers to ensure premium quality fiber optic products that will create the finest optical fiber communication system.

Fiber optic couplers (adapters) are designed to connect two fiber optic cables together. Adapters can connect single fibers together (simplex) as well as, two fibers (duplex.) Multimode and single-mode applications are available; along with, both APC and UPC polished connectors. offers ST, SC, LC and FC.

Specifications
Insertion Loss (dB): ≤0.20dB
Repetitiveness (dB): ≤0.10dB
Interchangeability (dB): ≤0.20dB
Plug times: 1000times
Tensile strength: 200~600G
Operating temperature -40---+70°C
Storage temperature -40---+85°C
Humidity: 95%RH (Non-Packaging)
Sleeve material : Zirconia
Housing Material : High Quality Plastic
Exactitude size
Easy Installation
Applicable standard: IEC 61754-13

Features

1. Low insertional loss and back reflection loss

2. High prcision alignment

3. Nickel plated brass body

4. Use in Single-mode or Multimode applications

5 .Choice of housing material and sleeve material

6. ISO9001:2008,ROHS compliance

Applications

1. CATV

2. Telecommunication networks

3. Test equipment

4. Metro

5. Local Area Networks(LANs)

6. Data processing networks
