Tight Buffered 900um LC Pigtail Multimode , Optical Pigtail For Ethernet Systems
Tight Buffered 900um LC Pigtail Multimode , Optical Pigtail For Ethernet Systems
Specifications
Brand Name :
FOCABLE
Model Number :
LC OM3 Fiber Optic Pigtail
Certification :
ISO, RoHS Compliant
Place of Origin :
China
MOQ :
10pcs
Packaging Details :
1PCS/Blister Box
Cable :
PVC, LSZH, OFNP, OFNR, Hytrel
Cores :
Simplex, Duplex, 2core, 4core, 6core, 8core, 12core, 24core
Fiber :
OS1, OS2, OM1, OM2, OM3, OM4
Outer Diameter :
0.9mm, 1.6mm, 2.0mm, 2.4mm, 3.0mm
Connector :
FC, FC/APC, SC, SC/APC, LC, LC/APC, ST, E2000, MU, MTRJ, MPO
Length :
1M, 2M, 3M, 5M or as per customer request
Description

Tight Buffered 900um LC Pigtail Multimode , Optical Pigtail For Ethernet Systems

Fiber Optic Pigtail is a length fiber cable with connectors fixed on one end. If both sides of the connector or its end-face are different, we call it hybrid patch cord. According to the transmission medium, it divides Single Mode and Multi Mode; According to the connector structure type, it divides FC, SC, ST, MU, D4, LC etc. According to the polished ceramic end-face, it divides PC, UPC and APC.

We supply fiber optic pigtails, including the single mode and multimode types, These fiber pigtails are with premium grade connectors and with typical 0.9mm outer diameter cables. Simplex fiber pigtail, duplex fiber pigtails and multi core pigtails are all available, with different cable color, cable diameter and jacket types optional.

Features
Low insertion and back reflection loss
Good exchangeability, durability
Pigtail or patch cord can be ordered

Compliant with the standard of IEC
High Return Loss and Low Insertion Loss.
Good reliability and stability
Polishing type: PC, UPC, and APC
Various interfaces: FC, SC, ST…
Core of cable: 4, 6, 8, 12, 24…

Applications
Telecommunication network
Testing Equipment
Local Area Network
CATV

Specifications

parameter unit Multi-fiber connector
SM MM
PC UPC APC PC
Insertion Loss (Typical) dB ≤0.3 ≤0.3 ≤0.3 ≤0.3
Return Loss dB ≥40 ≥50 ≥60 ≥25
Wavelength nm 1310, 1550 850,1310
Exchangeability dB ≤0.2
Vibration dB ≤0.2
Operating Temperature °C -40~85
Storage Temperature °C -40~85
Cord diameter mm Φ3.0, Φ2.0, Φ0.9
Fiber Count F 4, 6, 8, 12,24fiber…
Connector Available FC, SC, ST, LC, MU,MTRJ, MPO

Ordering Information

Cores Count

01=simplex, 02=duplex, ..., 06=6cores, ..., 12=12cores, 24=24cores

Fiber Type

1=G652D, 2=G657A, 3=OM3,50/125um 4=OM4 5=OM1, 62.5/125um, 6=OM2, 62.5/125um

Cable Outer Diameter

L=900µm Loose or tight tube, S=2.0mm, R=3.0mm, X=others

Cable Length

0.5-20M=0.5--20m, X=Others

Connector Type

FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC, ST=ST/UPC, LU=LC/UPC, LA=LC/APC, 00=None, X=Others

Tight Buffered 900um LC Pigtail Multimode , Optical Pigtail For Ethernet Systems

Fiber Optic Pigtail, Optical Fiber Pigtail, Fiber Pigtail, Fiber Pigtails
