Multi Mode LSZH Jacket Fiber Optic Ethernet Cable SC-FC Connector
Multi Mode LSZH Jacket Fiber Optic Ethernet Cable SC-FC Connector
Specifications
Brand Name :
FOCABLE
Model Number :
SC-FC MM Simplex Fiber Patch Cord
Certification :
RoHS Compliant, SGS Certificate, ISO Certificate
Place of Origin :
China
MOQ :
10PCS
Delivery Time :
3-5days
Packaging Details :
1PCS/PE Bag
Fiber Type :
SM, OM1, OM2, OM3, OM4
Cable Material :
PVC, LSZH, OFNP, OFNR, Hytrel
Cable Diameter :
0.9mm, 1.6mm, 1.8mm, 2.0mm, 2.4mm, 3.0mm
Connector :
SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST, E2000, MU, MPO, MTRJ
Cores :
Simplex, Duplex, 4cores, 6cores, 8cores, 12cores, 24cores, 48cores
Length :
1M, 2M, 3M, 5M or as per customer request
Description

Multi Mode LSZH Jacket Fiber Optic Ethernet Cable SC-FC Connector

We offer a range of superior-quality, simplex, multi-mode, LSZH fiber optic patch cords. Fiber optic patch cords are non-conductive and immune to electrical noises. They provide convenient connections between fiber optic converters and fiber optic patch panels, and are regularly used with fiber optic equipment.

LSZH stands for Low Smoke Zero Halogen. The inner structure and parameters of a LSZH cable are similar to other types of fiber optic cables, such as PVC. What makes the LSZH cable stand apart from other cables is its jackets. The LSZH fiber optic jacket is more fire-resistant than PVC jacketed cables. Should they catch on file, the burning LSZH cables give off low smoke and no halogen substances, which is important not only for the environment but also for the people and facilities nearby the cables. Therefore, LSZH fiber optic cables are widely used in crowded areas like high-rise buildings, commercial centers, sports centers, airports, and libraries.

Features

Core Diameter: 62.5/125 micron

Insertion loss: typically <0.2 dB

Return loss: >35dB

Ceramic Ferrules for increased durability

Used primarily for high speed data communications such as Gigabit Ethernet

Ultra Physical Contact (UPC) Polished Fiber

Built with Corning Glass

Telcordia’s GR-326-Core, IEC Standard

Green Production, RoHS Standard

Excellent Polished and 100% tested.

High stability various environments

Customize order available

Specifications

Mode SM MM
Polish UPC APC PC
Insertion Loss ≤0.2dB ≤0.3dB ≤0.2dB
Return Loss ≥55dB ≥65dB ≥35dB
Interchangeability ≤0.2dB
Salt Spray ≤0.1dB
Repeatability ≤0.1dB (1000 times)
Vibration ≤0.2dB (550Hz 1.5mm)
Temperature ≤0.2dB (-40+85 sustain 100 hours)
Humidity ≤0.2dB (+25+65 93 R.H.100 hours)
Apex Offset 0μm ~ 50μm
Radius of Curvature 7mm ~ 25mm

Rem
