FTTA Outdoor Waterproof IP67 LC LC Fiber Patch Cord
FTTA Outdoor Waterproof IP67 LC LC Fiber Patch Cord
FTTA Outdoor Waterproof IP67 LC LC Fiber Patch Cord
FTTA Outdoor Waterproof IP67 LC LC Fiber Patch Cord
Specifications
Brand Name :
FOCABLE
Model Number :
FTTA Patch Cord LC-LC 4F
Certification :
RoHS Compliant, SGS Certificate, ISO Certificate
Place of Origin :
China
MOQ :
10PCS
Delivery Time :
3-5days
Packaging Details :
1PCS/PE Bag
Fiber Type :
G.652D, G.657A, G.655, SM or MM
Cable Material :
LSZH, TPU
Cable Diameter :
2.0mm, 0.9mm
Connector :
SC/APC, SC/UPC, LC/APC, LC/UPC
Cores :
4 core
Length :
1M, 2M, 3M, 5M or as per customer request
Armored :
Non-armored, armored
Quality Control :
100% test before shipping
Description

LC-LC Fiber Patch Cord FTTA Outdoor IP67 Waterproof GYFJH Cable 4 Fiber

GYFJH type cable fiber optic patch cord is widely used for RRU, base station, FTTA and outdoor waterproof conditions, suitable for fiber optic networks transmission in harsh environment. The cable jacket is LSZH, flame retardant, waterproof, anti-rat. There are several branches aramid yarn to resist high tensile strength. The cable is soft, easy to wire and small space available. It is with metal tube to protect the fiber.

Features

Standard Duplex LC connector, well connected with standard LC adaptor

Available Single mode (G.657A, G.652D) and multi-mode (OM1, OM2, OM3, OM4)

Broad temperature range and wide range of indoor and outdoor cables

Dust, Moisture, Waterproof design.

Easy Operation, reliable and cost-effective installation

Low insertion loss, high return loss, steady optical transmitting

LSZH, PVC, OFNP, OFNR, TPU outer jacket can be provided as per request

Applications

FTTA, FTTH

3G, 4G Base Station

BBU, RRU, RRH, LTE

Harsh outdoor environments applications

Specifications of FTTA Armored Patch Cord

Item Data
Insertion Loss ≤0.3dB
Mechanical life 500cycles
Storage temperature -40°C~+70°C
Operating temperature -10°C~+50°C
Protection Level IP67
Tensile strength Tensile between junction and fiber cable≥180N
Outer sheath flame retardant UL94 V-0
Outer sheath UV resistant UL 746C

FTTA Outdoor Waterproof IP67 LC LC Fiber Patch Cord
