Specifications
Brand Name :
OEM ODM
Model Number :
4GE 4WIFI GPON ONU Wifi EPON XPON 4002XR
Certification :
FCC, RoHS, ce
Place of Origin :
Guangdong, China
MOQ :
100PCS
Price :
US$35-US$38
Payment Terms :
Western Union, T/T.Paypal
Supply Ability :
4000pcs per week
Packaging Details :
1 pcs in a box , requirements are available
Name :
XPON ONU 4GE+AC WIFI BOB
Type: :
ONU
Transmission Distance :
20km
power supply: :
+12V,1.5A
LAN Interface: :
4 x 10/100/1000Mbps
Network: :
SDK, TCP, IP, wifi
Wifi: :
2.4G&5.8G
Optical interface: :
SC/UPC connector
Description

Fiber Optical 4GE+4WIFI GPON Dual Band ONU Wifi EPON XPON AC ONT Optical Network Unit Onu


Description:

designed as HGU (Home Gateway Unit) in different FTTH solutions. The carrier-class FTTH application provides data and video service access .

based on mature and stable, cost-effective XPON technology. It could switch automatically into EPON mode or GPON mode when access to the EPON OLT and GPON OLT.

adopts high reliability, easy management, configuration flexibility and good quality of service guarantees to meet the technical performance of EPON Standard of China Telecom CTC3.0 and GPON Standard of ITU-TG.984.X


Functional Feature:

Support EPON/GPON mode and switch mode automatically

Support Route mode for PPPoE/DHCP/Static IP and Bridge mode
Support IPv4 and IPv6 Dual mode

Specialized design for system breakdown prevention to maintain stable system

Support TR069 remote configuration and maintenance
Support LAN IP and DHCP Server configuration
Support Port Mapping and Loop-Detect

Support Firewall function and ACL function
Support 2.4G&5.8G WIFI and Multiple SSID

Support Port Mapping and Loop-Detect

Support IGMP Snooping/Proxy multicast feature



Specification:​

Technical item Details
PON Interface 1 GPON BoB(Class B+)
Receiving sensitivity:≤-27dBm
Transmitting optical power: +0.5~+5dBm
Transmission distance: 20KM
Wavelength TX: 1310nm, RX: 1490nm
Optical Interface SC/UPC Connector
Design Scheme RTL9607C+RTL8192FR(2.4G)+RTL8812ER(5G) BOB(RTL8290B)
Chip Spec CPU 950MHz,DDR2 128MB
Flash SPI NAND Flash 128MB
LAN Interface 4 x 10/100/1000Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Wireless Compliant with IEEE802.11b/g/n,ac
2.4G Operating frequency:2.400-2.4835GHz
5.8G Operating frequency:5.150-5.825GHz
2.4G 2*2 MIMO, rate up to 300Mbps
5.8G 2*2 MIMO ,rate up to 867Mbps
4 external antennas 5dBi
Support Multiple SSID
LED 9 LED, For Status of PWR,LOS,PON,LAN1~LAN4,2.4G,5.8G
Push-Button 2 ,For Function of Reset and WPS
Operating Condition Temperature: 0℃~+50℃
Humidity: 10%～90%(non-condensing)
Storing Condition Temperature: -30℃~+60℃
Humidity: 10%~90%(non-condensing)
Power Supply DC 12V/1A
Power Consumption ≤6W
Dimension 248mm×158mm×192mm(L×W×H)
Net Weight 0.3Kg
Storing Condition Temperature: -30℃~+60℃

Panel lights Introduction

Pilot Lamp Status Description
PWR On The device is powered up.
Off The device is powered down.
LOS Blink The device doses not receive optical signals or with low signals.
Off The device has received optical signal.
PON On The device has registered to the PON system.
Blink The device is registering the PON system.
Off The device registration is incorrect.
LAN1~LAN4 On Port (LANx) is connected properly (LINK).
Blink Port (LANx) is sending or/and receiving data (ACT).
Off Port (LANx) connection exception or not connected.
2.4G On 2.4G WIFI interface up
Blink 2.4G WIFI is sending or/and receiving data (ACT).
Off 2.4G WIFI interface down
5.8G On 5G WIFI interface up
Blink 5G WIFI is sending or/and receiving data (ACT).
Off 5G WIFI interface down


Application

​

  • Typical Solution:FTTH(Fiber To The Home)
  • Typical Business:INTERNET,IPTV,WIFI etc
