Specifications
Brand Name :
YINGDA
Model Number :
1X16 splitter module
Certification :
ISO
Place of Origin :
china
MOQ :
100 pcs
Price :
1.1USD-4.58USD
Supply Ability :
10,000 pcs per month
Delivery Time :
5-8days after payment
Packaging Details :
2pc/ box, 20pcs/carton box
split ratio :
1X16 blockless splitter
connector :
SC/APC simiplex
fiber type :
single mode G657A1
insertion loss :
13.6dB
Uniformity (Max.) :
1.4dB
wavelength :
1260 - 1650 nm
PDL(Max.) :
0.3dB
Standard :
Telcordia GR-1221 and GR-1209
tube dimension :
60*12*4mm
cable diameter :
0.9mm
cable color :
input white, output: colorful
Description


Broadband FTTH Splitter Coupler 1 x 16,1:16 Fiber Optic PLC Splitter Ribbon 900um SC APC Connectors For Fiber Optic Termination Box

Broadband FTTH Splitter Coupler 1 x 16,1:16 Fiber Optic PLC Splitter Ribbon 900um SC APC Connectors

Description
Planar lightwave circuit (PLC) splitter is a type of optical power management device
that is fabricated using silica optical waveguide technology. It features small size,
high reliability, wide operating wavelength range and good channel-to-channel uniformity,
and is widely used in PON networks to realize optical signal power splitting. YINGDA provides whole series of 1xN and 2xN splitter products that are tailored for
specific applications. All products meet GR-1209-CORE-2001 and GR-1221-CORE-
1999 requirements.

Features

1) Low Insertion loss
2) Low PDL
3) Compact Design
4) Good channel-to-channel uniformity
5) Wide Operating Wavelength: From 1260nm to 1650nm
6) Wide Operating Temperature: From -40℃ to 85℃
7) High Reliability and Stability

Applications

1) FTTX Systems
2) PON Networks
3) CATV Links
4) Optical Signal Distribution

Compliance

1) Telcordia GR-1209-CORE-2001
2) Telcordia GR-1221-CORE-1999
3) RoHS

More pictures

pack: 2pcs in a box with foam, there is fix place for steel tube and all connectors in order. Highly protec all the fibers and connectors when transportation.
Broadband FTTH Splitter Coupler 1 x 16,1:16 Fiber Optic PLC Splitter Ribbon 900um SC APC ConnectorsBroadband FTTH Splitter Coupler 1 x 16,1:16 Fiber Optic PLC Splitter Ribbon 900um SC APC Connectors
can put product name, serial number, and customer logo on the label.
each connectors have figure ring on the cable to identify which split it is.
If customer need , can use colorful tube for each cable for identification.

Broadband FTTH Splitter Coupler 1 x 16,1:16 Fiber Optic PLC Splitter Ribbon 900um SC APC Connectors Broadband FTTH Splitter Coupler 1 x 16,1:16 Fiber Optic PLC Splitter Ribbon 900um SC APC Connectors
Technical Characteristics
1×N PLC Splitter

Parameter

Unit

Value

Product Type

1×2

1×3

1×4

1×6

1×8

1×12

1×16

1×24

1×32

1×64

1×128

Operation Wavelength

nm

1260～1650

Insertion Loss

Typ.

dB

3.6

6.0

7.0

9.2

10.3

12.2

13.6

15.8

16.6

20.1

24.5

Max.

4.3

6.2

7.4

9.5

10.7

12.5

13.9

16.0

17.2

21.5

25.5

Uniformity (Max.)

dB

0.5

0.6

0.8

0.8

0.8

1.2

1.4

1.5

1.5

2.0

2.6

PDL(Max.)

dB

0.2

0.3

0.3

0.3

0.3

0.3

0.3

0.3

0.3

0.5

0.8

TDL(Max.)

dB

0.5

Return Loss

dB

≥55/50

Directivity

dB

≥55

2×N PLC Splitter

Parameter

Unit

Value

Product Type

2×2

2×4

2×8

2×16

2×32

2×64

2×128

Operation Wavelength

nm

1260～1650

Insertion Loss

Typ.

dB

4.2

7.2

10.6

13.8

17.0

20.5

24.8

Max.

4.5

7.7

11.0

14.8

17.9

21.5

25.8

Uniformity (Max.)

dB

0.8

1.0

1.2

1.5

1.8

2.5

3.0

PDL(Max.)

dB

0.2

0.3

0.3

0.3

0.3

0.5

1.0

TDL(Max.)

dB

0.5

Return Loss

dB

≥55/50

Directivity

dB

≥55

Note: All the data above does not include connectors.

UPC Connectors: IL add 0.2 dB, APC Connectors: IL add 0.3 dB.
