500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine
500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine
Specifications
Brand Name :
DST
Model Number :
DSC-1000U
Certification :
SGS
Place of Origin :
China
MOQ :
1set
Price :
Based on Specification
Payment Terms :
T/T
Supply Ability :
5 sets in 4 months
Delivery Time :
around 4 months
Packaging Details :
wooden case
Substrate :
OPP 2 - 12um
Substrate Width :
500mm - 920mm
Slitting width :
min 4.5 mm
Unwinding dia :
max. 650mm
Winding dia. :
max. 350mm
Speed :
max. 500m / min
Size :
2200mm(L) x 2300mm(W) x 1,500mm(H)
PLC :
Beckhoff
Tension sensor :
E+L
DC24V Power Supply :
Siemens
Description

Automatic High Speed Film Slitting Rewinding Machine Servo Motor Driven Slitter Rewinder Machine

Product Description

Electric control:

Operation screen:

HMI color touch screen

Screen functions: power switch, process parameter setting, sensor head position, parameter calibration, digital I / O, analog I / O, operation status, alarm signal display, etc.

Features

1. Horizontally moving, front placed rewind arms
2. Horizontally moving slitting cartridge
3. Controlled individual trim winder
4. Electrostatic Eliminator
5. Margin tracking system
6. Pre-clearing system
7. Operator-oriented graphic touch panel
8. Digital winding technique with AC servo drives
9. Closed-loop controlled unwind
10. Fault diagnostic function
11. Wave cutting system(Optional)

Technical Data

Substrate OPP 2 - 12um
Substrate Width 500-920mm
Slitting width min 4.5 mm
Electricity 3 phase * 200 volt *60Hz
Unwinding diameter max. 650mm
Winding dia. max. 350mm
Speed max.500m/min
PLC Beckhoff Germany
Operation screen Colorful touch screen , HMI
Power supply AC380V, 50Hz,three phase current

500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine

Competitive Advantages

1. We offer high quality products at competitive price;
2. customs clearance is guaranteed;
3. Good after-sale service;
4. Flexible payment terms;
5. With excellent products and efficient services, we are well known both at home and abroad.

Packaging & Delivery

1. Prompt delivery;
2. Professional logistic agent;
3. Well-trained and disciplined packing team;
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.

500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine

Our Factory

500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine

500m/Min Horizontal Slitter Rewinder Machine , Roll Winding Machine

FAQ

Q: Is Dongsheng a factory or trading company?

A: Dongsheng is a factory.

Q:Where is your factory located? Can I visit it before I place an order?

A:Our factory is located in Hefei, Anhui,China; Welcome to visit our factory.

Q: How about the warranty and after-sale service?

A: We provide 12 months warranty and lifetime technic suport for all machinery.

The response is available within 12 hours while the solution for the troubleshooting is provided within 48 hours.

Q. Payment Terms

A. TT 30% down payment, 70% before shipment.

Q. Machine installation

A. We could assign the technician to the place for the on-site installation if requested by the purchaser.
