BOPP 50micron Silicone Coated Film, Customizable Ratio Of Release Force On Each Side, Silent Tape, Sealing Tape.
BOPP 50micron Silicone Coated Film, Customizable Ratio Of Release Force On Each Side, Silent Tape, Sealing Tape.
BOPP 50micron Silicone Coated Film, Customizable Ratio Of Release Force On Each Side, Silent Tape, Sealing Tape.
BOPP 50micron Silicone Coated Film, Customizable Ratio Of Release Force On Each Side, Silent Tape, Sealing Tape.
BOPP 50micron Silicone Coated Film, Customizable Ratio Of Release Force On Each Side, Silent Tape, Sealing Tape.
BOPP 50micron Silicone Coated Film, Customizable Ratio Of Release Force On Each Side, Silent Tape, Sealing Tape.
Specifications
Brand Name :
HSF
Model Number :
PBIH50-0815
Place of Origin :
China
MOQ :
30,000 square meters
Supply Ability :
10000 kg per week
Delivery Time :
within 10 days
Packaging Details :
PE wrap + bubble film + processed wooden pallet
Price :
$0.27 / s.q.m. for quantities less than 100,000 square meters, on FOB Shanghai basis
Material :
Polypropylene
Color :
Natural
Surface :
Matte, silicone coated
Thickness :
50 micron (up to 80)
Width :
1060mm (200mm ~ 1600mm)
Winding length :
Customized
Haze :
≥76
Feature :
High tensile strength, excellent ink and coating adhesion, excellent grease barrier
Release Force :
Customizable ratio of release force on both sides based on customer requirements, such as one is to two or one is to three
Description

Biaxially oriented polypropylene matte film, after silicone coating on one or both sides, has excellent smoothness, anti-adhesive and abrasion resistance. Therefore, it can be applied in the following fields:

1. Packaging industry:

For food packaging, pharmaceutical packaging, cosmetic packaging, etc., it can improve the opening performance of the packaging, making it easier to open.

2. Printing industry:

Used for surface treatment of printed materials to enhance the glossiness and smoothness of the printed materials, making them easier to read.

3. Electronics industry:

t can be used for the packaging of electronic products such as mobile phones, computers, etc., to provide anti-skid and anti-scratch protection.

4. Label industry:

hen making labels, silicone coating can improve the peeling performance of the labels, making them easier to stick and remove.

5. Industrial field:

In some industrial products, such as conveyor belts, waterproof rolls, etc., silicone coating can increase the abrasion resistance and slip resistance of the products.

6. Tape industry:

BOPP release film is also widely used in sealing tape and silent tape.

The specific application depends on the type and amount of silicone coating, as well as other properties of the matte film. When selecting and using it, comprehensive considerations should be made based on specific requirements.

Name of Comm. BOPP Matte Double Side Release Film Model Number PBIH50-0815
Test Item Standard Request Typical Data Results
Appearance Wrinkle, particle, damage, impurity,contamination Not allowed No Ok
Stripe, burst vein, scratch, pucker Slight allowable Slight Ok
Number white point & crystal points Φ0.2-0.5/㎡ 0-80 40 Ok
Φ0.6-1.0/㎡ 0-20 10 Ok
More than Φ1.0/㎡ Not allowed 0 Ok
Size T Avg. ±5.0% 49.5 Ok
T Ultimate Deviation ±6.0% 3 Ok
T Average Deviation ±3.0% 0.2 Ok
  • Deviation
 ±2.0% No Ok
Mechanical Properties

Tensile Strength

(MPa)

 MD ≥ 100 133 Ok
TD ≥ 160 265 Ok
Elongation @ Break (%) MD ≤ 180 182 Ok
TD ≤ 65 57 Ok

Shrinkage

(%)

 MD ≤ 4.0 3.0 Ok
TD ≤ 2.0 0.5 Ok

Friction Coefficient

Us/Ud

 Inside 0.25-0.50 0.22/0.20 Ok
Outside 0.25-0.50 0.21/0.19 Ok
Glossiness ≤ 15 4.8 Ok
Haze ≥ 76 93.4 Ok
Release Force Side A

gf/25mm (20 min.)

TESA 7475 Finat 10

 5-8 6 Ok
Side B 10-15 13.5 Ok
Subsequent Adhesion Rate Side A

% (20hr)

NITTO 31B Finat 11

 ≥85 89 Ok
Side B ≥85 92 Ok
Inspection Conclusion Fulfill the technical standard
