Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
5rolls
Price :
usd
Delivery Time :
Generally 20days(according to your quantity need)
Packaging Details :
waterproof paper with plastic cloth, then put into wooden case.
Payment Terms :
T/T, Western Union, L/C at sight
Wire Diameter :
0.025-1.8mm
Mesh/Inch :
1-200mesh
Weave Type :
Plain Weave, Twill Weave
Feature :
Corrosion Resistance
Usage :
Oil Filter
Color :
Black, Siver
Certification :
ISO9001:2015
Description

Titanium mesh is lightweight and about 60% of the specific gravity of stainless steel wire mesh, thermal expansion coefficient is about 50% of the stainless steel wire cloth. In addition, about half of the stainless steel mesh and has a initialized modulus is also flexible nature.

Characteristics: Chemical resistance is a summary of the nitric acid - strong acid system, and withstand seawater, also wet chlorine gas. For high-strength, corrosion resistance without deterioration due to cold, stress corrosion, has a feature almost no pitting.

Titanium wire mesh is used for living organisms because non-toxic, it can be used such as artificial bone, will also be in direct, fit into the body. And other chemical equipment, oil refining equipment, industrial equipment, etc. It can also be used for pulp and paper.

Weave Pattern: plain weave and twill weave, Perforated Mesh also offer.

3 to 200 mesh, Corrosion Resistance Titanium Wire Mesh/Fabric With TA1, TA2, GR2, GR3, R50250, Titanium Alloy etc

3 to 200 mesh, Corrosion Resistance Titanium Wire Mesh/Fabric With TA1, TA2, GR2, GR3, R50250, Titanium Alloy etc

The table below shows the most popular specification:

Specification List of Titanium Wire Mesh
Mesh/Inch Wire Dia Mesh Opening Opening Area Mesh /Inch Wire Dia Mesh Opening Opening Area
mm mm A mm mm A
d w % d w %
3 0.8 7.67 82.00% 20 0.3 0.97 58.30%
4 1 5.35 71.00% 20 0.35 0.92 52.50%
4 0.89 5.46 74.00% 24 0.25 0.808 57.90%
5 1 4.08 64.50% 30 0.28 0.567 45.00%
6 0.8 3.433 65.80% 32 0.25 0.544 46.50%
8 0.81 2.365 55.40% 35 0.23 0.496 46.90%
9 0.8 2.022 51.30% 40 0.25 0.385 36.00%
10 1 1.54 36.80% 40 0.21 0.425 44.80%
10 0.635 1.905 56.20% 50 0.18 0.328 41.70%
12 0.6 1.517 51.30% 60 0.15 0.273 41.70%
14 0.406 1.408 60.20% 80 0.12 0.198 38.70%
16 0.45 1.138 51.30% 80 0.1 0.218 46.90%
18 0.254 1.157 67.20% 100 0.1 0.154 36.80%

Our titanium wire mesh weaving from 3mesh to 100mesh. Other specifications please inform us.
