60Mesh Plain Weave Brass Wire Cloth, 0.10-0.19mm Wire, H65(65%Cu35%Zn)
60Mesh Plain Weave Brass Wire Cloth, 0.10-0.19mm Wire, H65(65%Cu35%Zn)
60Mesh Plain Weave Brass Wire Cloth, 0.10-0.19mm Wire, H65(65%Cu35%Zn)
60Mesh Plain Weave Brass Wire Cloth, 0.10-0.19mm Wire, H65(65%Cu35%Zn)
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
1rolls
Price :
Negotiable
Payment Terms :
T/T, L/C at sight
Delivery Time :
in 25days
Packaging Details :
Inside with a paper tube, outside with a piece of waterproof, then in wooden case.
Material :
Brass Wire H65
Common Wire Diameter :
0.15mm
Common Width :
1.0m
Common Length :
30m
Weave :
Plain Weave
Usages :
Sieving diversified pellet, powder, porcelain clay and glass, filtering liquid and gas.
Certification :
ISO9001:2015
Description
Brass Wire Mesh/Brass Wire Cloth
Brass woven wire cloth is also called papermaking cloth. It is made of 65% copper and 35% zinc.
Papermaking cloth is made of phosphor bronze wire in the wrap, which has outstanding tension stress, bending force, wear resistance and expansion force and brass wire in the weft, which has proper tension stress and extensibility. Mesh refers to the wire quantity per inch. The fewer mesh, the bigger aperture size and better water permeability.
60Mesh Plain Weave Brass Wire Cloth, 0.10-0.19mm Wire, H65(65%Cu35%Zn)
80mesh Brass Wire Mesh Specifications:
Material H65 Weave Type Plain Weave
Mesh 60 Wire Diameter 0.15mm
Width 1.0m Length 30.0m
Opening Area 42% Aperture 0.273mm
Mesh Counts Wire Diameter Aperture Open Area Rate Weight
mm Inch mm Inch % kgs/㎡ lbs/㎡
60 0.10 0.0039 0.323 0.0127 58.30 0.33 0.72
0.11 0.0040 0.313 0.0123 54.76 0.41 0.90
0.12 0.0047 0.303 0.0119 51.34 0.48 1.05
0.15 0.0059 0.273 0.0107 41.68 0.76 1.67
0.17 0.0066 0.253 0.0099 35.81 0.97 2.13
0.19 0.0074 0.233 0.0091 30.38 1.22 2.68
Application of brass mesh and brass wire cloth

The brass woven wire cloth can be used in the paper making industries for dewatering.
Can be used as the woven wire filter cloth for solid, liquid and gas in the industries, chemical and lab.

Can be used in sieving diversified pellet, powder, porcelain clay and glass, filtering liquid and gas.

60Mesh Plain Weave Brass Wire Cloth, 0.10-0.19mm Wire, H65(65%Cu35%Zn)

Features of brass mesh and brass wire cloth
1) Abrasion, corrosion, high temperature and spark resistance.
2) Acid, alkali resistance.
3) Durable, good ductility, tensile strength.
4) Allowing light, air, liquid to pass.
5) Discolor due to atmospheric condition.
6) Not suitable for salt water application.
7) Clean and install easily.
8) Brass mesh has lower electricity and heat conductivity but better abrasion and corrosion resistance, better tensile strength compared with copper mesh cloth.

Specifications:
Width: 0.914M, 1M, 1.5M.
Length/roll: 30M.
Weaving methods: plain weave, twill weave or dutch weave.


Our main specifications

Mesh Wire Dia. Opening(mm)
SWG mm inch
6 22 0.711 0.028 3.522
8 23 0.61 0.024 2.565
10 25 0.508 0.02 2.032
12 26 0.457 0.018 1.66
14 27 0.417 0.016 1.397
16 29 0.345 0.014 1.243
18 30 0.315 0.012 1.096
20 30 0.315 0.0124 0.955
22 30 0.315 0.0124 0.84
24 30 0.315 0.0124 0.743
26 31 0.295 0.0116 0.682
28 31 0.295 0.0116 0.612
30 32 0.247 0.011 0.573
32 33 0.254 0.01 0.54
34 34 0.234 0.0092 0.513
36 34 0.234 0.0092 0.472
38 35 0.213 0.0084 0.455
40 36 0.193 0.0076 0.442
42 36 0.193 0.0076 0.412
44 37 0.173 0.0068 0.404
46 37 0.173 0.0068 0.379
48 37 0.173 0.0068 0.356
50 37 0.173 0.0068 0.335
60×50 36 0.193 0.0076 -
60×50 37 0.173 0.0068 -
60 37 0.173 0.0068 0.25
70 39 0.132 0.0052 0.231
80 40 0.122 0.0048 0.196
90 41 0.112 0.0044 0.17
100 42 0.012 0.004 0.152
120×108 43 0.091 0.0036 -
120 44 0.081 0.0032 0.131
140 46 0.061 0.0024 0.12
150 46 0.061 0.0024 0.108
160 46 0.061 0.0024 0.098
180 47 0.051 0.002 0.09
200 47 0.051 0.002 0.076

Other specifications according to your requirements.
