Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire
Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire
Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire
Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire
Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire
Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
5 rolls
Price :
Negotiable
Payment Terms :
T/T, L/C at sight, Western Union
Delivery Time :
Generally in 25days. According to required quantity.
Packaging Details :
Each roll with polyfilm with water proof paper outside/wooden pallets.
Material :
Stainless Steel, Carbon Steel, Aluminum, Copper, Nickel
Type :
Flat Top Crimped Mesh
Weave Style :
Plain Weave
Technique :
Pre-Crimped Then Woven
Aperture Size :
4mm, 6mm, 8mm, 10mm, 12mm, 15mm, 16mm, 20mm, 25mm, 30mm, 40mm, 50mm, 60mm
Wire Diameter :
1.6mm, 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 5mm
Features :
Flat Surface, Accurate Openings, High Rigidity and Strength, Strong Wear Resistance, Firm Structure
Applications :
Architectural, decorative, food, mining & aggregate industries
Certification :
ISO9001:2015
Description

Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire

Flat Top Crimped Wire Mesh

Flat top crimped, also called pressed crimped, is made from round and profiled plain weave wire. All the mesh knuckles is being on the underside. The structure is very heavy and durable. The smooth surface is the characteristic of the weaving method. This structure can allow the materials to move more freely over the screen.

It is widely used in the architectural & decorative industries, for the screen of fence, facade and ceiling; In the agricultural & food industries, for pig raising screens; In the mining & aggregate industries,vibrating machine.

Weave Pattern: Flat-top Curved

Stainless Steel Flat Top Crimped Wire Mesh, 4-60mm Opening, 1.6-5mm Wire

Material:

Standard materials of flat top crimped wire mesh are low/mild/high carbon steel and stainless steel 201, 202, 304, 316, 321, 410, 430.

Besides above following material available:
Copper: brass, pure copper, phosphor bronze
Aluminum: 1050, 1060, 1100, 5052, 5056
Nickel: pure nickel, nickel alloy, monel

Features:
Stainless Steel Wire mesh can resist severe circumstances like low/high temperatures, high pressures, acids, alkaline solutions, easily be fabricated with various weaving types in the weaving loom, and also have hygienic characteristics, easily clean ability, can withstand various weather conditions and have a highly aesthetic appeal, highly durable and can withstand severe circumstances over a longer period of time.

Usage:
Fine stainless steel flat top crimped mesh is widely used in processing of oil, chemical, food, making wire mesh filter, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making and so on.

Coarse stainless steel mesh can be widely used in sand, rock, coal, gavel, metal material screening, quarry aggregate, mining industries, road construction industries, asphalt mixing plant and so on.

Specifications:
Opening Sizes: from 4mm to 60mm.

Wire Diameters: from 1.6mm to 5.0mm.

Roll Width: 1m, 1.22m, 1.5m to 4m.

Roll Length: 15m, 30m to 60m.

Panel Width: 0.5m, 0.914m, 1m, 1.22m to 2m.
Panel Length: 1m, 1.22m, 1.5m to 6m.

Flat Top Crimp Wire Mesh
Opening Wire Diameter Open Area
mm Inch mm Inch %
4.0 0.157 1.6 0.063 51.02
6.0 0.236 2.0 0.079 56.25
8.0 0.315 2.0 0.079 64.00
10.0 0.394 2.0 0.079 69.44
1.6 0.063 74.32
12.0 0.472 5.0 0.197 49.83
3.0 0.118 64.00
2.0 0.079 73.47
15.0 0.591 2.5 0.098 73.47
2.0 0.079 77.85
16.0 0.630 4.0 0.157 64.00
3.0 0.118 70.91
20.0 0.787 3.0 0.118 75.61
2.5 0.098 79.01
2.0 0.079 82.64
25.0 0.984 4.0 0.157 74.32
3.0 0.118 79.72
30.0 1.181 3.0 0.118 82.64
40.0 1.575 5.0 0.197 79.01
4.0 0.157 82.64
3.0 0.118 86.53
50.0 1.969 5.0 0.197 82.64
4.0 0.157 85.73
3.0 0.118 89.00
60.0 2.362 5.0 0.197 85.21

Other Specifications according to your requirements.

Packing: Crimped wire mesh is packed in rolls,wrapped in moisture-proof paper or plastic film, outside wooden cases or wooden pallet.
