Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
5 rolls
Price :
Negotiable
Payment Terms :
T/T, L/C at sight, Western Union
Delivery Time :
According to required quantity.
Packaging Details :
Inside with a paper tube(Cylindrical Cardboad paper core inside), outside with a piece of waterproof
Material :
Q195, Q235, Q275
Mesh Counts :
10mesh to 80mesh
Weave Style :
Plain Weave
Width :
1.0m, 1.2m, 1.5m; 36", 48"
Length :
30m; 100ft
Applications :
Oil industry and cereal sifter ,etc.
Certification :
ISO9001:2015
Description
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh
Mild Steel Wire Mesh
Mild steel wire mesh is a kind of Square Hole Mesh woven of mild steel wire. It is also known as low carbon steel wire cloth or black cloth.
Material: Super quality low carbon steel wire.
Mild steel is excellent for the manufacture of industrial wire cloth due to its tensile strength and impact resistance.
Applications: Black mild steel wire mesh is mainly processed in filter discs for filtration of rubber industry, plastic industry and grains.
Weaving Type: Plain Weave
Mild Steel Wire Mesh(Also Called Low Carbon Steel Wire Mesh), 10-80Mesh


Mild Steel Wire Mesh Specifications:
Normally Mesh Counts: 10mesh to 80mesh in square opening.
Width: 36", 48", 0.6m, 1m, 1.2m.
Roll Length: 30m, 100ft.
Other sizes also available at customers specific requirements.

Mesh/InchWire Diameter(mm)
100.9, 0.8, 0.7, 0.6, 0.5, 0.4
120.8, 0.7, 0.6, 0.5, 0.4, 0.3
140.7, 0.6, 0.5, 0.4, 0.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19
160.6, 0.5, 0.4, 0.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19
180.5, 0.4, 0.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15
200.5, 0.45, 0.4, 0.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15
220.4, 0.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15
240.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15, 0.13, 0.12
300.35, 0.3, 0.27, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15, 0.13, 0.12
320.28, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15
350.3, 0.28, 0.25, 0.23, 0.21, 0.19, 0.17, 0.15
400.27, 0.25, 0.23, 0.21, 0.19
500.19, 0.17, 0.15
600.17, 0.15
800.14, 0.13
