600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter
600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter
600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter
600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
5rolls
Price :
usd
Payment Terms :
T/T, L/C at sight, Western Union
Delivery Time :
In 20days
Packaging Details :
Inside with a paper tube, outside with a piece of waterproof, then in wooden case or pallets.
Material :
SS316L
Mesh Count :
600mesh
Wire Dia. :
0.018mm
Width :
48" or 1.22m
Length :
100ft or 30.5m
Weave Type :
Twill Weave
Certification :
ISO9001:2015
Description

Fine Stainless Steel Woven Wire Cloth

Stainless Steel 316L 600mesh Wire Cloth including 600 wires and openings of 1 inch, Using 0.018mm diameter wire, by twill weaving. Mainly used for acid, alkali conditions screening and filtering, the oil industry as mud mesh, chemical fiber industry do screen mesh, plating industry as pickling network, gas, liquid filtration and separation with other media. Anping wire mesh production experience for many years has had several stainless steel mesh production enterprises, the production of stainless steel mesh filter with stable performance, fine.

600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter

Specifications:

Specifications US Metric
Mesh Size 600/Inch 600/2.54cm
Wire Diameter 0.0007” 0.018mm
Width 48” 1.22m
Length 100ft 30.5m
Packing: Water-proof paper first then plastic film, in wooden case or pallets.
Nearest Port: Tianjin(By Sea); Beijing(By Air).

Material: 316L stainless steel: Similar properties as 316ss but lower carbon content to permit better welding.

AISI Chemical Composition
C Si Mn P S Ni Cr Mo
316L Max.0.03 Max.1.00 Max.2.00 Max.0.045 Max.0.030 12.00~15.00 16.00~18.00 2.00~3.00

Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.

600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter


Characteristics:

High tension, much higher tension than common polyester mesh,and this property is very suitable.

Super precision: uniform wire diameter and aperture with extremely low difference.

Low elongation: very small elongation of wire mesh at high tension.

High flexibility: the wire mesh will not lose elasticity at extreme tension.

High corrosion resistance: the excellent corronsion resistance of stainless steel wire exceeds polyester fiber.

Non-electrostatic: to avoid affects of nonelectrostatic for printing and ensure the safety of priting.

Good heat melting resistance:special features of steel wire mesh suitable for heta-melting ink.

Good solvent resistance: to avoid the affects of any solvents to wire mesh.


Applications:
This kind of stainless steel wire mesh are widely used in such fields as environmental protection, pharmaceutical industry, chemical industry, food industry, mechanical industry, smelting industry, coal mining, paper making, cement, construction industry, decoration, aeronautics and astronautics and so on.

Standard Specifications:

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB) /100 Square Foot
Inch MM Inch MM
90X90 0.005 0.127 0.0061 0.16 30.1 15.8
100X100 0.0045 0.114 0.0055 0.14 30.3 14.2
100X100 0.004 0.102 0.006 0.15 36 11
100X100 0.0035 0.089 0.0065 0.17 42.3 8.3
110X110 0.004 0.1016 0.0051 0.1295 30.7 12.4
120X120 0.0037 0.094 0.0064 0.1168 30.7 11.6
150X150 0.0026 0.066 0.0041 0.1041 37.4 7.1
160X160 0.0025 0.0635 0.0038 0.0965 36.4 5.94
180X180 0.0023 0.0584 0.0033 0.0838 34.7 6.7
200X200 0.0021 0.0533 0.0029 0.0737 33.6 6.2
250X250 0.0016 0.0406 0.0024 0.061 36 4.4
270X270 0.0016 0.0406 0.0021 0.0533 32.2 4.7
300X300 0.0051 0.0381 0.0018 0.0457 29.7 3.04
325X325 0.0014 0.0356 0.0017 0.0432 30 4.4
400X400 0.001 0.0254 0.0015 0.37 36 3.3
500X500 0.001 0.0254 0.001 0.0254 25 3.8
635X635 0.0008 0.0203 0.0008 0.0203 25 2.63

Other specifications according to your requirements.

Packing: Water-proof paper first then plastic film, in wooden case or pallets.

600Mesh Twill Weave Wire Cloth, SS316L Grade, 0.018mm Wire Diameter
