Cut Edge Stainless Steel Woven Wire Mesh, 13Mesh Stainless Steel 304/316
Cut Edge Stainless Steel Woven Wire Mesh, 13Mesh Stainless Steel 304/316
Cut Edge Stainless Steel Woven Wire Mesh, 13Mesh Stainless Steel 304/316
Cut Edge Stainless Steel Woven Wire Mesh, 13Mesh Stainless Steel 304/316
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
5Rolls
Payment Terms :
T/T, Western Union, L/C at sight
Delivery Time :
In 15days
Packaging Details :
Wrapped with moister-barrier paper, then in wooden cases.
Material :
SS304
Mesh Count :
13
Wire Diameter :
0.5mm
Width :
1.2m
Length :
30m
Edge :
Cut Edge
Certification :
ISO9001:2015
Description

Stainless Steel Cut Edge Wire Mesh

Cut Edge Stainless Steel Woven Wire Mesh, 13Mesh Stainless Steel 304/316
Materials: SS304 316, 304L, 316L, etc.
Standard: AISI, SUS, EN.
Weaving: plain woven wire cloth. For Twill weave and Dutch weave mesh, it can be customized.
Application:
It can be processed into filter discs of various sizes
It can be cut into size panels in all shapes including, squares, rectangles and circles in all materials and mesh sizes
Black wire cloth is mainly used in filtration mesh of rubber, plastic, petroleum and grains industry
Selvage style: welded selvage, closed selvage, returned selvage and flash


Characteristics and usage:
stainless steel wire mesh is heat-resisting, acid-resisting and corrosion-resisting. This kind of wire mesh is widely used in mining, chemicals, food products and others.

Specification

Mesh/Inch Wire Diameter Aperture Open Area
(%)		 Weight
(kg /Square meter)
Inch MM Inch MM
4X4 .047 1.19 .203 5.16 81.2 2.7
5X5 .041 1.04 .159 4.04 79.5 2.6
6x6 .035 0.89 .145 3.68 2.1
8 x 8 .32 0.81 .113 2.88 2.6
10X10 .025 .64 .075 1.91 74.9 2.0
12X12 .020 .508 .063 1.60 75.9 1.5
14X14 .020 .508 .051 1.30 71.9 1.8
16X16 .018 .457 .0445 1.13 71.2 1.6
18X18 .017 .432 .0386 .98 69.4 1.6
20X20 .020 .240 .0300 .76 76.0 .56
20X20 .016 .330 .0340 .86 72.2 1.1
30X30 .0120 .305 .0213 .54 63.9 1.4
30X30 .0094 .240 .0243 .62 72.1 .84
40X40 .0100 .254 .0150 .38 59.9 1.3
50X50 .0055 .140 .0145 .368 72.4 .48
60X60 .0047 .120 .0120 .303 71.6 .42
60X60 .0059 .150 .0107 .273 64.5 .65
80X80 .0055 .140 .0069 .117 45.5 .76
100X100 .0045 .114 .0055 .140 55.1 .59

Other specifications according to your requirements.
