Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30
Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30
Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30
Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
1roll
Price :
usd
Payment Terms :
T/T, Western Union, L/C at sight
Delivery Time :
Generally 20days(according to your quantity need)
Packaging Details :
waterproof paper with plastic cloth, then put into wooden case.
Material :
Titanium
Mesh/Inch :
100
Wire Diameter :
0.1mm
Aperture :
0.154mm
Certification :
ISO9001:2015
Description

Nichrome Wire Mesh is an ideal material, because it has relatively high resistance and forms an adherent layer of chromium oxide when it is heated for the first time. Material beneath the Conveyor Belt will not oxidize, preventing the Conveyor Belt from breaking or burning out. So Nickel Chromium Wire Mesh is good for anti-corrosion and high resistant co-efficiency. So Nickel Chromium Wire Cloth is applicable for heat treatment, air-carbon furnace, chemical industry, machinery, metallurgy.
Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30
Material: Cr20Ni80, Cr15Ni60, Cr20Ni30

Grade%NiCrFeAlMnSiCPS
Cr20Ni80MinBal20--0.60.750.080.020.08
Max2310.21.6
Cr15Ni60Min5515Bal--0.750.080.020.15
Max61180.50.61.6
Cr20Ni35Min3418Bal-110.10.030.025
Max37210.53


Characteristics:
Deformation ability, thermal stability, mechanical character, shockproof ability in thermal state and anti-oxidization. For heating, resistance Conveyor Belt must be stable in air when hot.

Applicatioins:
Used in Heating Elements, High-Temperatures Uses, Igniters, etc
Most Popular Specification:
Mesh Counts: 4-325
Hole Shape: Square, Rectangle
Width: 5mm-1500mm
Weave Pattern: plain weave, twill weave.
Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30

Specification List of Nichrome Wire Mesh
Mesh/InchWire DiaMesh
mmOpening mm
dw
41.64.75
81.191.98
80.120.303
100.891.65
160.511.09
200.410.86
400.250.385
800.120.197
2000.050.077
3250.0350.043


Packing: waterproof paper with plastic cloth,then put into wooden box.
Ideal Material Nichrome Wire Mesh--Cr20Ni80, Cr15Ni60, Cr20Ni30
