Plain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making Filters
Plain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making Filters
Plain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making Filters
Plain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making Filters
Specifications
Brand Name :
Tenglu
Place of Origin :
Hengshui
MOQ :
5Rolls
Price :
usd
Payment Terms :
T/T, L/C at sight, Western Union
Delivery Time :
In 25days
Packaging Details :
Inside with a paper tube(Cylindrical Cardboad paper core inside), outside with a piece of waterproof.
Material :
Copper/Brass Wire
Mesh/Inch :
2 to 500
Weave Type :
Plain Weave
Width :
0.5m to 3.0m
Certification :
ISO9001:2015
Description
Material: Brass wire, phosphor bronze wire, or copper wire.
Application of brass mesh and brass wire cloth

Decorative mesh for lamps, cabinets and entertainment centers.

Plumbing screen, filter discs, fireplace screen, window and porch screen.

Sculpture, craft, BBQ grill.

Filter in food, mine, paper making, machine, pharmaceutical, chemical, metallurgy, industry, electricity, commercial and so on.

Sieving and filtering granule, powder, porcelain clay and glass, chinaware printing, grain, filtering liquid and gas.

Plain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making FiltersPlain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making Filters

Plain Weave Brass Filter Wire Mesh/Wire Cloth Used for Making Filters

Features of brass mesh and brass wire cloth
1) Abrasion, corrosion, high temperature and spark resistance.
2) Acid, alkali resistance.
3) Durable, good ductility, tensile strength.
4) Allowing light, air, liquid to pass.
5) Discolor due to atmospheric condition.
6) Not suitable for salt water application.
7) Clean and install easily.
8) Brass mesh has lower electricity and heat conductivity but better abrasion and corrosion resistance, better tensile strength compared with copper mesh cloth.

Specifications:
brass wire cloth 6 mesh/inch - 160 mesh/inch;
copper wire cloth 10 mesh/inch - 60 mesh/inch;
phosphor bronze wire cloth 120 mesh - 360 mesh/inch.
Width: 0.914M, 1M, 1.5M.
Length/roll: 30M.
Weaving methods: plain weave, twill weave or dutch weave.


Our main specifications

Mesh Wire Dia. Opening(mm)
SWG mm inch
6 22 0.711 0.028 3.522
8 23 0.61 0.024 2.565
10 25 0.508 0.02 2.032
12 26 0.457 0.018 1.66
14 27 0.417 0.016 1.397
16 29 0.345 0.014 1.243
18 30 0.315 0.012 1.096
20 30 0.315 0.0124 0.955
22 30 0.315 0.0124 0.84
24 30 0.315 0.0124 0.743
26 31 0.295 0.0116 0.682
28 31 0.295 0.0116 0.612
30 32 0.247 0.011 0.573
32 33 0.254 0.01 0.54
34 34 0.234 0.0092 0.513
36 34 0.234 0.0092 0.472
38 35 0.213 0.0084 0.455
40 36 0.193 0.0076 0.442
42 36 0.193 0.0076 0.412
44 37 0.173 0.0068 0.404
46 37 0.173 0.0068 0.379
48 37 0.173 0.0068 0.356
50 37 0.173 0.0068 0.335
60×50 36 0.193 0.0076 -
60×50 37 0.173 0.0068 -
60 37 0.173 0.0068 0.25
70 39 0.132 0.0052 0.231
80 40 0.122 0.0048 0.196
90 41 0.112 0.0044 0.17
100 42 0.012 0.004 0.152
120×108 43 0.091 0.0036 -
120 44 0.081 0.0032 0.131
140 46 0.061 0.0024 0.12
150 46 0.061 0.0024 0.108
160 46 0.061 0.0024 0.098
180 47 0.051 0.002 0.09
200 47 0.051 0.002 0.076

Other specifications according to your requirements.
