10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
Specifications
Applicable Industries :
Food & Beverage Factory, Printing Shops, Food & Beverage Shops
Weight (KG) :
0.5
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
PLC, Engine
Place of Origin :
Shandong, China
Brand Name :
huisidun
Warranty :
1 Year
Product name :
Membrane Pleated Filter Cartridge
OEM :
Accept Oem
Filter medium :
PP Fibre Membrane
Size :
10'' 20'' 30'' 40''
maximum filtered water flow :
20inch filter element: 660LPM
Certification :
RoHS/ISO9001
Applicable water source :
Municipal Tap Water
Filter material :
Polypropylene Filter Medium
Maximum allowable operating temperature :
folding PP:82℃
Application :
Industrial
Packaging Details :
According to customer requirements
Port :
qingdao
Supply Ability :
50000000 Piece/Pieces per Year
MOQ :
100 pieces
Price :
$2.33 - $4.51/pieces
Description
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
Product Description
Brand
HuiSiDun
Filter medium
PES Fibre Membrane/PP Polypropylene
Support layer
Polypropylene (PP)
Filter cage
Polypropylene (PP)
Pore size
0.1,0.2,0.45,0.65,1µm
Length
5/10/20/30/40 inches
OD/ID
69 mm-34 mm
Gasket / O - rings
Silicone, NBR, EPDM, Viton
Interface
DOE,215,222,226flat/fins
End caps
DOE,0050,0050A,0050B
Sealing method
thermal bonding technique
Effective filtration area
0.6 m2/10"
Max. operating temperature
PES Fibre Membrane:140℃, 0.28 Mpa/PP Polypropylene:85℃/0.2 MPa; 25 ℃ (≥ 0.4 MPa)
Max. forwarder differential pressure
0.42 Mpa (25℃)
Max. reverse differential pressure
0.21 Mpa (25℃)
Sterilizing temperature
121℃ 30min
PVDF for liquid filtration
PVDF membrane for liquid filtration.
Absolute Rating
Filtration effective is ≥99.99%
Minimum pore size is 0.1um, suitable for critical liquid filtration
Wide Chemical
Suitable for strong alkaline and acid enviroment
compatability
Resistance to the halogens and oxide
High viscosity liquid filter
Best choice for critical filtration of high viscosity liquid.
Materials
Filter Media: PVDF Membrane
PVDF Membrane: Polypropylene
Inner core: Polypropylene /SUS304
Outer Support: Reinforced Polypropylene Cage
Adapter: Polypropylene
Operating Conditions(操作条件）
Normal Operating Temperature: Up to 65℃ (149℉) ）
Max.Operating Temperature.: 90℃ (194℉)at P≤1.0 bar (14psi)
Normal Flow direction 4.2 bar (60 psi) at 25℃ (77℉);
Reverse flow direction 2.1 bar (30psi) at 25℃ (77℉)
PH Value compatibility: 1-13
Details Images
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are a professional manufacturer of all kinds of filtercartridges,housings and filtration systems. We provide you the total filtration solutions with our 15 years experience in theindustry. Asyou can see, Huiston is the hottest searching word in Alibaba.com. Thanks for finding us here.
2. Q: May I have samples?
A: Sure,of course. Sample cost can be refunded if you place formal orders in the future.
3. Q: Can you make customized products?
A: Yes,of course if you can provide us detailed specifications or drawings. Our mission is make customer idea on the products andprovide the customer satisfied solutions.
4. Q: Can I use our own designed package?
A: Yes, size, color, logo and packaging style all can be customized.
5. Q: What’s your MOQ?
A: Normally, 300 PCS/item. Any trial order which is less than MOQ is warmly welcomed. If you have a trialorder, please feel free to contact us so that we can make some shipping recommendation for you to save the cost based on the quantity you need.
6. Q: I am a small business owner, Can I buy from you?
A: Yes, you are warmly welcomed. To grow with our customer is our goal.We would like to grow with you together.
7. Q: What is your general lead time?
A: Normally 3-7working days for off-the-shelf samples and 14-25 days for bulk production. 8. Q: How should I pay you? A: We strongly recommend Trade Assurance service on the Alibaba platform. T/T, L/C, Western Union,MoneyGram,etc are acceptable.
9. Q: What certificate do you have?
A: Our factory is ISO9001/OHSAS18000 certified. We have Environmental management，Raw material food grade etccertificate for the products we are manufacturing. and we have two private brands
10:Q: How should I place an order?
A: Please kindly click” send inquiry”or “contact supplier”, Then our sales engineer will recommend you suitable products for your selection also give some valuablesuggestion for your selection.
11:Q: Since you are famous, can I be your agent?
A: Welcome to join us, we are happy to have afurther discussion with you. Let’s work together to make the world cleaner, safer and more productive.
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
10'' 226 Fins PTFE Microporous Pleated Folding Filter for Large Scale Filtration Needs
