2.5 Inch 8bar PVC Lining White Fire Hose for Water Transporting
TA fire hose is a high-pressure hose used to carry water or other fire retardant (such as foam) to a fire to extinguish it. Outdoors, it is attached either to a fire engine or a fire hydrant. Indores, it can be permanently attached to a building's standpipe or plumbing system.
We provide single layer fire hose, double layer hose with PVC lining, EPDM rubber lining, etc. The material of hose can be PVC fire hose, rubber fire hose, canvas fire hose. The hose fits different occasions with a service pressure range from the 8-25 bar.
Technical Parameter
1) The lining of fire hose is PVC, Rubber or Copy Rubber .
And the jacket of fire fighting hose is wovenby high intensity of polyester filament or polyester short-fiber( twill/plain ).
2) There are special adhesive ( solid or liquid)between the jacket and the hose.
The canvas hose is soft and highly polished, reduce the flow resistance
3) The fire hose is thinner and softer, lighter and more convenient to use.
4) The fire hose is high pressure resistance, low temperature resistance, anti-corrosion,aging resistance,wear-resisting.
5) We supply different color lining of fire hose : blue, black, transparent, etc or according to your requirement
6) We supply different length of firehose : 10m - 30m or according to your requirement
7) The fire hose is packed by poly bag and cartons.
8) The quality of fire hose is guranteed by CCCF, ISO9001:2008
9) The hose use in fire fighting or agriculture
Diameter (Inch/mm) | Working Pressure (MPa/BAR/PSI) | Testing Pressure (MPa/BAR/PSI) | Bursting Pressure (MPa/BAR/PSI) | Length (M/FEET) |
1 25 | 0.8/ 8/120 1.0/10/150 1.3/13/195 1.6/16/240 2.0/20/300 | 1.2/12/180 1.5/15/220 2.0/20/300 2.4/24/360 3.0/30/450 | 2.4/24/360 3.0/30/450 3.9/39/580 4.8/48/720 6.0/60/900 | 10 15/50 20 25 30/100 |
1.5 40 | ||||
2 50 | ||||
2.5 65 | ||||
3 80 | ||||
3.5 90 | ||||
4 100 | ||||
4.5 115 | ||||
5 125 | ||||
5.5 140 | ||||
6 150 | ||||
8 200 | ||||
10 250 |
With a history of more than 20 years, Shenzhen Winan Industrial Development Co. Ltd. is a professional manufacturer and exporter who are focusing on designing, developing and manufacturing all kinds of Fire fighting equipment. The company now has a large area of industrial workshops of more than 10000 square meters, located in Shenzhen, China, with convenient transportation access.
All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. As a result of our high-quality products and outstanding customer service, we have gained a global sales network around the world.
Certificates:
All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. As a result of our high quality products and outstanding customer service, we have gained a global sales network around the world.
FAQ:
1. Do you offer free sample for your clients?
?????Yes, we can offer you free sample.
2. What's the MOQ of your products?
?????MOQ is ONE pcs/set.
3. Are you manufacturer with your own factory?
?????Yes, we are the manufacturer for more than 20 years
4. What's your?payment terms?
?????We accept T/T, L/C, Western Union, Paypal,etc.
5. How long is the?delivery time?
?????Usually around 15 days after payment.
6.?Can you accept OEM?
????Yes, we do customized design for our clients.
