Electric Winches 750 LB P750-1 Φ3mm X 15m Cable Permanent Magnet Motor
Electric Winches 750 LB P750-1 Φ3mm X 15m Cable Permanent Magnet Motor
Specifications
Brand Name :
J&M
Model Number :
P750-1
Place of Origin :
China
MOQ :
100 SETS
Payment Terms :
L/C, T/T
Delivery Time :
30 DYAS
Rated line pull: :
Single- line pull : 750lbs(337kg) Double-line pull: 1500lbs (680kg)
Overall dimension: :
285mm x 105mm x 105mm
Cable :
Φ3mm x 15m
Drum Dimensions :
Φ30mm x 72mm
Description

Electric Winches 750 LB P750-1 Φ3mm X 15m Cable Permanent Magnet Motor

Specifications:

Rated line pull Single- line pull : 750lbs(337kg) Double-line pull: 1500lbs (680kg)
Motor 0.3kw/0.4hp 12V, permanent magnet
Gear reduction ratio 153:1
Drum Dimensions Φ30mm x 72mm
Cable Φ3mm x 15m
Mounting dimension Φ8.5mm x 80mm
Battery cable 1.83m
Overall Dimensions 285mm x 105mm x 105mm
Packing size 33.5X16X37 cm
Weight N.W/G.W:10kgs/11kgs
Export Markets Europe,North America etc
Standard Met CE

Electric Winches 750 LB P750-1 Φ3mm X 15m Cable Permanent Magnet Motor
