N - 3a High Temperature Brick With 30%-48% AL2O3 / Fireclay Heat Proof Bricks
N - 3a High Temperature Brick With 30%-48% AL2O3 / Fireclay Heat Proof Bricks
N - 3a High Temperature Brick With 30%-48% AL2O3 / Fireclay Heat Proof Bricks
N - 3a High Temperature Brick With 30%-48% AL2O3 / Fireclay Heat Proof Bricks
Specifications
Brand Name :
Jundao(Henan)
Model Number :
N-3a N-3a FireClay Bricks
Certification :
ISO9001:2015
Place of Origin :
Henan China
MOQ :
20
Price :
Negotiate
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5500ton/mon
Packaging Details :
Fumigated wooden pallet, plastic or steel bandages strapped and the whole outside is wrapped with thermoplastic film.
Color :
Red
Material :
Fireclay
Size :
Customized
C.C.S :
≥19.6MPa
A.P :
≤24%
Certificate :
ISO9001
Refractoriness （℃，Min） :
1710
Description

High Quality N-3a FireClay Bricks With 30%-48% AL2O3 Sell Well In Singapore

Multipurpose Fireclay brick manufactured by us takes clay clinker as aggregate and refractory soft clay as binding agent. It is a universal refractory products with 30%-48% AL2O3 content. The refractoriness fluctuates from 1580°C to 1700°C. The products fluctuates in a very wide range and the differences in production processes, thus its properties fluctuate within a wide range.

Fireclay bricks features:

1.Have good thermal shock resistance,

2.Large fluctuation range, generally more than 10 times (water cooling at 1100°C);

3.Coefficient of linear expansion of clay products; average line expansion between 20°C and 1300°C the coefficient is (4.5-5.8)×10-6°C-1;
4. The fireclay refractory material is a weakly acidic refractory product and its acidity increases as the SiO2 content increases;

5.It has a certain erosion resistance to the acid slag, and poor resistance to alkaline slag erosion.

Therefore, fireclay fireproof products should be used as lining for acid slag furnaces.

N - 3a High Temperature Brick With 30%-48% AL2O3 / Fireclay Heat Proof Bricks

Specification:
Fire clay Brick A.P(%,Max)

C.C.S

(Mpa,Min)

R.U.L
(0.2Mpa,℃,

Min)

 R.L.C(%) Refractoriness(℃,Min)
1400℃*2h 1350℃*2h
N-3a 24 40 1320 / +0.2
-0.5		 1710
Remark ISO Certificated; Customized
