Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Specifications
Brand Name :
Yixing ICS
Certification :
ce
Place of Origin :
Jiangsu, China
MOQ :
1 Set/Sets
Price :
$5,000.00 - $100,000.00 / Set
Supply Ability :
50 Set/Sets per Quarter
Ice Shape :
Flake Ice
Condition :
New
Voltage :
220~380V
Power :
70kw
Dimension(L*W*H) :
customize
Weight :
depends
Warranty :
1 Year
After-sales Service Provided :
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Capacity :
10 ton
Name :
flake ice making machine
Compressor :
Bitzer
Cooling way :
Evaporative Cooling
Application :
Fresh-keeping/fishery
Material :
SUS304 Staineless Steel
Refrigerant :
R404a/R22
Expansion valve :
Danfoss Brand
Control system :
PLC+Touch Screen
Solenoid valve :
Saginomiya (Japan)
Type :
Automatic Flake Ice Machine
Description

Special design of flake ice machine:

1. Refrigerating unit -- Compressor are imported from America, Germany, Japan. 2. PLC programmable control system -- The whole system is controlled automatically well without hand operation. 3. Evaporator-- made of SUS304/316 material and adopts automatic fluorine welding technology. 4. Ice blade--Spiral ice blade, small resistance, low loss, no noise and making ice in uniform.
PRODUCT SPECIFICATIONS
TECHNICAL DATA
Model
MIF5T-R4A
The technical data based on
25℃ambient temp.
20℃water inlet temp.
The evaporating temperature
-20℃
The condensing temperature
38℃
Power supply
3P/380V/50Hz
The ice thickness
1.6-2.3mm
Refrigerant
R404A
Daily Output(Ton/24hrs)
5tons
Cooling Capacity(kw)
38.7
General Power(kw)
22.55
Compressor Input(kw)
20.5
Reductor Power(kw)
0.37
Cooling Mode
Air Cooling
Water Inlet/ Drain Pipe
3/4”;1/2"
Weight(kg)
980
Dimension(mm)
2030*1500*1470
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Flake ice is a kind of irregular ice with size about 40*40 mm and thickness around 1-2 mm.
The thin ice can be directly used for stirring and mixing refrigerated materials.
Besides, flake ice has no acute edges and corners so it will not damage the surface of cooled object.
With large contact area and fast cooling speed, flake ice can realize high efficiency cooling effects.
SPECIFICATIONS FOR 1 TON FLAKE ICE MACHINE
MODEL
DAILY CAPACITY
REFRIGERANT
OPERATING POWER
OPERATING WEIGHT
BYF-10AS
1 TON
R404A
5KW
200KG
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz

Main Features

1) Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.

2) stainless steel materials, advanced processing equipment and heat treatment processing ensure the best heat transfer efficiency.

3) The design of large water receiving plate can prevent water leaking at the bottom of evaporator

4) Direct liquid feeding and dry evaporation, simple&safe to control.

5) Integrated modular design, convenient to install and maintain.

Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Detailed Images
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz

Flake ice is easy to crush and mold, with almost zero damage to the cooled products.

The internal structure of the evaporator is specially designed to improve the heat-exchange efficiency and to keep the loop unblocked with special processing technology.

Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz

The internally scraping ice making mode has been adopted, which reduces the loss of energy and avoids the leakage of refrigerant.

Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Certifications

CE Certificate Number:

M.2019.206.C0141

Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Related Products
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz

Slurry Ice Machine

96% Response Rate

Flake Ice Machine

94.8% Response Rate

Cold Room

98% Response Rate

Our Service
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Packing & Delivery
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Activities
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
Automatic 1 2 3 5 Flake Ice Maker Machine 10 Ton 3P 380Volt 50Hz
About Yixing ICS

Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive mordern manufacture of all kinds ice making plants, cold room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.

ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China.
