Specifications
Brand Name :
Yixing ICS
Certification :
ce
Place of Origin :
Jiangsu, China
MOQ :
1 Set/Sets
Price :
$5,000.00 - $100,000.00 / Set
Supply Ability :
50 Set/Sets per Quarter
Ice Shape :
Flake Ice
Condition :
New
Voltage :
220~380V
Power :
70kw
Dimension(L*W*H) :
customize
Weight :
depends
Warranty :
1 Year
After-sales Service Provided :
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Capacity :
10 ton
Name :
flake ice making machine
Compressor :
Bitzer
Cooling way :
Evaporative Cooling
Application :
Fresh-keeping/fishery
Material :
SUS304 Staineless Steel
Refrigerant :
R404a/R22
Expansion valve :
Danfoss Brand
Control system :
PLC+Touch Screen
Solenoid valve :
Saginomiya (Japan)
Type :
Automatic Flake Ice Machine
Description
Model Number
LR-03T, LR-05T, LR-1T, LR-2T, LR-3T, LR-4T, LR-5T, LR-6T, LR-8T, LR-10T, LR-12T, LR-15T, LR-20T, LR-30T, LR-40T
Capacity
300kg/day, 500kg/day, 1 ton/day, 2 tons/day, 3 tons/day, 4 tons/day 5 tons/day, 6 tons/day, 8 tons/day, 10 tons/day, 12 tons/day,
15 tons/day, 40 tons/day, 50 tons/day, 100 tons/day
Applicable Industries
Food & Beverage Factory, Restaurant, Food Shop, Energy & Mining, Food & Beverage Shops
After Warranty Service
Video technical support, Online support
Ice Shape
Snow Flake Ice
ower supply
3P/1P + 380V/220V/110V + 50hz/60hz
Power
18.49~53.42kw
Dimension(L*W*H)
1850*1700*1555~3900*2150*1920mm
Weight
672KG ~ 2250KG
Core Components
Pressure vessel, Motor, Bearing, Gear, Engine, PLC
After-sales Service Provided
Engineers available to service machinery overseas
Refrigerant
R404A
compressor
Bitzer from Germany, Refcomp from Italy, Danfoss from Danmark
cooling type
water cooling
ice thickness
1.8~2.5mm
Warranty
12 months

Special design of flake ice machine:

1. Refrigerating unit -- Compressor are imported from America, Germany, Japan. 2. PLC programmable control system -- The whole system is controlled automatically well without hand operation. 3. Evaporator-- made of SUS304/316 material and adopts automatic fluorine welding technology. 4. Ice blade--Spiral ice blade, small resistance, low loss, no noise and making ice in uniform.
Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons
Flake ice is a kind of irregular ice with size about 40*40 mm and thickness around 1-2 mm.
The thin ice can be directly used for stirring and mixing refrigerated materials.
Besides, flake ice has no acute edges and corners so it will not damage the surface of cooled object.
With large contact area and fast cooling speed, flake ice can realize high efficiency cooling effects.
SPECIFICATIONS FOR 1 TON FLAKE ICE MACHINE
MODEL
DAILY CAPACITY
REFRIGERANT
OPERATING POWER
OPERATING WEIGHT
BYF-10AS
1 TON
R404A
5KW
200KG
Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons

Main Features

1) Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.

2) stainless steel materials, advanced processing equipment and heat treatment processing ensure the best heat transfer efficiency.

3) The design of large water receiving plate can prevent water leaking at the bottom of evaporator

4) Direct liquid feeding and dry evaporation, simple&safe to control.

5) Integrated modular design, convenient to install and maintain.

Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons
Detailed Images
Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons
Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons

Flake ice is easy to crush and mold, with almost zero damage to the cooled products.

The internal structure of the evaporator is specially designed to improve the heat-exchange efficiency and to keep the loop unblocked with special processing technology.

Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons

The internally scraping ice making mode has been adopted, which reduces the loss of energy and avoids the leakage of refrigerant.

Fresh Keeping Industrial Flake Ice Maker Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons
