Chamber Wheel Tracking Machine Equipment Standard IEC60112 7 Inch Programmable Controller

The IEC60112 Comparative Tracking Index Test Apparatus is in accordance with GB4207, IEC60112 standards. IEC60112 Comparative Tracking Index Test Apparatus is suitable for lighting, low voltage electrical equipment, household appliances, electrical machines, motors, power tools, electronic equipment , electrical instruments. It also applies for insulation, plastic, electrical connectors, accessories industry.

TRACKING TESTET APPARATUS OF 5202 LEAKAGE TESTER

Model:5202

Accord with standard:GB4207 IEC60112

Technology data:

1. controller:7 inch programmable controller
2. voltage display:digital voltage model, touch screen display
3. current display:digital current model. Touch screen display
4. dimensions:1120w*600d*1020h
5. inner volume: ≥0.5cubic
6. electrode material:platinum
7. electrode size:2*5*35mm
8. electrode pressure:1.00N
9. electrode distance:4.0mm
10. liquid drop volume:50 drop/cubic meter
11. drop height:35mm(can be adjustable)
12. drop time:30s+-0.1(can be setted)
13. drop number:1~9999(can be setted)
14. test voltage:50v~600v(can be adjustable)
15. power supply voltage drop:1.0A+-0.1A<8%
16. up mark judgment:0.5A+-0.05A

Features:

1.) 7 inch full touch screen control system

2.) imported electrical accessories

3.) imported micro drop liquid pump

4.) drop time and volume control precision

5.) test qualified /unqualified judgment function

6.) test data USB can be saved directly

7.) door open close protect system

8.) overvoltage protect system

9.) full operation protect system

10.) tempered glass window

Main configure:

1.) standard electrode *1

2.) imported micro pump *1

3.) explosion prevention tempered glass *2

4.) standard liquid *1

5.) standard ruler *1
